| # | Part | Description | Price | Req | Notes | Availability |
|---|
1a |
275-5200
|
36V 3 stage vacuum motor kit |
$328.40
|
1 |
(includes 2-4) (OEM) |
usually ships 3-26 days |
1b |
991-1202-D
|
36V 3 stage vacuum motor tangential with Delphi plug |
$107.86
|
1 |
(NON-OEM) |
ships same day |
1c |
275-5200
|
36V 3 stage vacuum motor kit |
$328.40
|
1 |
(before SN 10355628) (includes 2a, 3b, and 4b) |
usually ships 3-26 days |
2a |
164-0881
|
Vacuum motor gasket |
$12.20
|
1 |
(OEM) |
usually ships 3-5 days |
2b |
991-3029
|
Vacuum motor gasket |
$1.89
|
1 |
(NON-OEM) |
ships same day |
3a |
991-1221
|
Carbon brush without plastic cover (pkg of 2) |
$13.20
|
1 |
(before SN 10355628) |
usually ships 5-16 days |
3b |
275-5816
|
Carbon brush kit (pkg of 2) |
$27.50
|
1 |
(after SN 10355629) |
usually ships 5-16 days |
4a |
175-5275
|
Housing |
$19.60
|
1 |
(5680) (before SN 10355628) |
usually ships 5-16 days |
4b |
175-6954
|
Cooling fan cover |
$16.90
|
1 |
(5680) (after SN 10355629) |
usually ships 5-16 days |
5 |
175-2152
|
P clamp |
$3.00
|
1 |
|
usually ships 1-5 days |
6 |
175-2162
|
Nylon wire tie |
$2.20
|
2 |
|
usually ships 5-16 days |
7a |
999-0499
|
Bolt M8-1.25 x 20mm hex head full thread stainless steel |
$1.85
|
3 |
(before SN 10000000) |
ships same day |
7b |
275-4736
|
Screw M8-1.25 x 20mm hex washer head stainless steel SEMS |
$3.00
|
3 |
(after SN 9999999) |
ships same day |
8 |
999-0355
|
Washer 3/8 x 7/8 SAE flat stainless steel |
$0.99
|
4 |
(before SN 10000000) |
ships same day |
9 |
175-2311
|
Inlet hose |
$32.40
|
1 |
|
ships same day |
10 |
175-2202
|
Nylon wire tie |
$3.00
|
1 |
|
ships same day |
11 |
175-2326
|
Cable |
$12.70
|
1 |
|
ships same day |
12a |
999-0784
|
Screw M8-1.25 x 16mm hex head stainless steel |
$1.74
|
1 |
(before SN 10000000) |
ships same day |
12b |
375-1163
|
Screw M8-1.25 x 16mm with washer stainless steel (OBSOLETE) |
Call for price
|
1 |
(after SN 9999999) |
usually ships 1-5 days |
13 |
175-2153
|
Vacuum fan mounting bracket |
$31.80
|
3 |
|
ships same day |
14 |
175-2256
|
Hose hanger clip |
$6.00
|
1 |
(before SN 9999999) |
ships same day |
15 |
175-2363
|
Screw 10-16 x 3/4 hex head thread forming |
$3.00
|
1 |
(before SN 9999999) |
ships same day |
16a |
175-2259
|
Vacuum fan filter |
$18.40
|
1 |
(5700) (before SN 006955) |
ships same day |
16b |
991-9073
|
Vacuum fan filter |
$6.04
|
1 |
(NON-OEM) |
ships same day |
N/S |
275-5200
|
36V 3 stage vacuum motor kit |
$328.40
|
1 |
(includes 2a, 3a, and 4a) |
usually ships 3-26 days |
