# | Part | Description | Price | Req | Notes | Availability |
1 |
175-3337
|
Door weldment 28 inch left side |
$179.11
|
1 |
|
usually ships 1-5 days |
2 |
175-3338
|
Skirt holder weldment left side |
$157.74
|
1 |
|
usually ships 5-16 days |
3 |
175-3339
|
Door weldment 28 inch right side |
$105.49
|
1 |
|
usually ships 5-16 days |
4 |
175-3340
|
Skirt holder weldment right side |
$157.74
|
1 |
|
usually ships 5-16 days |
5 |
175-3341
|
Clevis pin |
$3.96
|
2 |
|
ships same day |
6 |
175-2117
|
Cotter pin |
$3.96
|
6 |
|
ships same day |
7 |
175-3342
|
Protective tape |
$14.52
|
4 |
|
usually ships 5-16 days |
8 |
175-3343
|
Side squeegee blade linatex |
$64.46
|
2 |
|
ships same day |
9 |
175-3344
|
Clevis pin |
$7.48
|
2 |
|
usually ships 5-16 days |
10 |
175-3345
|
Extension spring |
$9.13
|
2 |
|
ships same day |
11 |
999-1170
|
Bolt M10-1.5 x 20mm hex head stainless steel |
$3.06
|
2 |
|
ships same day |
12 |
175-3347
|
Washer .61 thrust |
$4.84
|
4 |
|
ships same day |
13 |
175-3348
|
Bell crank |
$55.77
|
2 |
|
usually ships 5-16 days |
14 |
175-3349
|
Sleeved bushing |
$12.32
|
2 |
|
ships same day |
15 |
475-3313
|
GUIDE, SQGE, SIDE, YELLOW |
$17.38
|
2 |
|
usually ships 5-16 days |
16 |
175-3351
|
Clevis pin |
$3.30
|
2 |
|
ships same day |
17 |
175-3352
|
T-nut M10-1.5mm |
$7.92
|
2 |
|
ships same day |
18 |
999-1324
|
Screw M8-1.25 x 20mm flat head stainless steel |
$0.99
|
2 |
|
ships same day |
19 |
175-3354
|
Thrust washer |
$9.68
|
4 |
|
usually ships 5-16 days |
20 |
175-3355
|
Sleeved bushing |
$6.60
|
2 |
|
usually ships 5-16 days |
21 |
999-0579
|
Nut M8-1.25 hex coarse thread zinc |
$0.99
|
2 |
|
ships same day |
22 |
999-0497
|
Nut M6-1 nylon insert lock stainless steel |
$1.03
|
2 |
|
ships same day |
23 |
999-0355
|
Washer 3/8 x 7/8 SAE flat stainless steel |
$0.99
|
2 |
|
ships same day |
24 |
175-3357
|
Squeegee blade retainer |
$11.00
|
2 |
|
ships same day |
25 |
175-3358
|
Squeegee side lock lever |
$17.49
|
2 |
|
usually ships 1-5 days |
26 |
175-3187
|
Washer nylon |
$3.30
|
2 |
|
usually ships 5-16 days |
27 |
999-1312
|
Screw M6-1 x 20mm hex head stainless steel |
$0.99
|
2 |
|
ships same day |
28 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.99
|
2 |
|
ships same day |
