| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
175-1656
|
Hose clamp |
$3.96
|
10 |
(from SN 10403557 to SN 10740686) |
usually ships 5-16 days |
2 |
175-1928
|
Plastic tee fitting |
$7.48
|
1 |
(from SN 10403557 to SN 10740686) |
usually ships 5-16 days |
3 |
175-6347
|
Hose 1/4 inch x 13 foot |
$27.61
|
1 |
(from SN 10403557 to SN 10740686) |
usually ships 5-16 days |
4 |
275-1796
|
Straight plastic fitting (Tennant Industrial) |
$5.01
|
1 |
(from SN 10403557 to SN 10740686) |
usually ships 5-16 days |
5 |
275-4757
|
Fitting assembly |
$35.20
|
1 |
(from SN 10403557 to SN 10740686) |
usually ships 5-16 days |
6 |
275-9954
|
Plastic strainer fitting (Tennant Industrial) |
$8.85
|
1 |
(from SN 10403557 to SN 10740686) |
usually ships 1-5 days |
7 |
175-6081
|
Hose clamp |
$4.84
|
3 |
|
ships same day |
8 |
275-1192
|
Hose 1/2 x 3 foot (Tennant Industrial) |
$48.60
|
1 |
(before SN 10740687) |
usually ships 5-16 days |
9 |
175-3329
|
Plastic tee fitting |
$5.83
|
1 |
(before SN 10740687) |
usually ships 5-16 days |
10 |
175-5234
|
Plastic fitting |
$5.83
|
1 |
|
usually ships 5-16 days |
11a |
275-9955
|
28 inch cylindrical head bracket |
$68.20
|
1 |
|
usually ships 1-5 days |
11b |
275-9956
|
32 inch cylindrical head bracket |
$67.76
|
1 |
|
usually ships 1-5 days |
11c |
275-9957
|
36 inch cylindrical head bracket |
$55.44
|
1 |
|
usually ships 1-5 days |
12a |
175-5239
|
28 inch spray bar bracket weldment |
$118.91
|
1 |
|
usually ships 1-5 days |
12b |
175-5235
|
32 and 36 inch spray bar bracket weldment |
$123.20
|
1 |
|
usually ships 1-5 days |
13 |
999-9097
|
Washer M8 flat stainless steel |
$0.99
|
6 |
|
ships same day |
14 |
999-0499
|
Bolt M8-1.25 x 20mm hex head full thread stainless steel |
$1.85
|
2 |
|
ships same day |
15 |
275-1505
|
Cap fitting |
$8.25
|
2 |
|
ships same day |
16a |
275-9424
|
28 inch spray bar tube assembly |
$77.00
|
1 |
(28 inch) |
usually ships 5-16 days |
16b |
275-1512
|
32 and 36 inch spray bar tube assembly |
$130.68
|
1 |
(32 and 36 inch) |
usually ships 5-16 days |
17 |
175-5236
|
Spray bar bracket |
$15.18
|
3 |
|
usually ships 1-5 days |
18 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.99
|
3 |
|
ships same day |
19 |
999-9116
|
Screw M6-1 x 12mm hex head stainless steel |
$0.99
|
3 |
|
ships same day |
20 |
175-2888
|
Bolt M8-1 1/4 x 25mm hex head |
$3.96
|
4 |
|
usually ships 5-16 days |
21 |
275-4944
|
Pressure switch |
$90.75
|
1 |
(after SN 10403556) |
usually ships 5-16 days |
22 |
175-3529
|
Brass fitting |
$4.95
|
1 |
(after SN 10403556) |
ships same day |
23 |
175-7795
|
Cable tie |
$3.85
|
2 |
(after SN 10403556) |
ships same day |
24 |
175-7303
|
1/4 inch union tee |
$10.12
|
1 |
(after SN 10403556) |
usually ships 5-16 days |
25 |
175-6024
|
Hosebarb |
$4.95
|
1 |
(from SN 10403557 to SN 10740686) |
usually ships 5-16 days |
26 |
175-1977
|
Fitting 1/4 x 3/8 |
$4.95
|
1 |
(from SN 10403557 to SN 10740686) |
usually ships 5-16 days |
27 |
175-6029
|
Straight tee |
$13.75
|
1 |
(from SN 10403557 to SN 10740686) |
ships same day |
28 |
175-4307
|
Hosebarb |
$11.99
|
1 |
(from SN 10403557 to SN 10740686) |
usually ships 5-16 days |
29 |
275-4752
|
Capacitor plug |
$17.16
|
1 |
(after SN 10403556) |
ships same day |
30 |
175-5468
|
Barbed fitting |
$5.61
|
1 |
(from SN 10403557 to SN 10740686) |
usually ships 1-5 days |
31 |
275-4756
|
Check valve |
$239.80
|
1 |
(from SN 10403557 to SN 10740686) |
usually ships 5-16 days |
32 |
275-4750
|
64 inch hose |
$65.56
|
1 |
(from SN 10403557 to SN 10740686) |
usually ships 1-5 days |
