| # | Part | Description |
Req | Notes | Availability |
|---|
000a |
N/A
|
Not available |
1 |
Hose in assembly form is no longer available. |
|
000b |
175-1979
|
25 foot solution hose assembly |
1 |
|
|
000c |
175-4882
|
50 foot vacuum and solution hose kit (OBSOLETE) |
1 |
Includes 001c, 002-004, 005c, 006-007 |
|
000c |
175-3590
|
25 foot vacuum hose assembly |
1 |
|
|
001a |
775-0278
|
15 foot solution hose assembly |
1 |
Included in 000a |
|
001b |
175-3587
|
25 foot solution hose assembly |
1 |
Included in 000b |
|
001c |
175-3538
|
20 inch base (black) |
1 |
Included in 000c |
|
001d |
991-8143
|
20ft 100psi vac/sol hose assembly w/1/4 female & 1/4 male |
1 |
(NON-OEM) |
|
002 |
991-8158
|
1/4 inch BH2-60 female coupler (mate to QD40) |
1 |
Included in 000a, 000b, or 000c |
|
003 |
991-8150
|
1/4 inch BH2-61 male nipple (mate to QD80) |
1 |
Included in 000a, 000b, or 000c |
|
004 |
175-6244
|
Nipple |
2 |
Included in 000a, 000b, or 000c |
|
005a |
175-3589
|
15 foot vacuum hose assembly |
1 |
Included in 000a |
|
005b |
175-3590
|
25 foot vacuum hose assembly |
1 |
Included in 000b |
|
005c |
175-3591
|
50 foot vacuum hose assembly |
1 |
Included in 000c |
|
006 |
175-6269
|
1 1/2 inch hose cuff (OBSOLETE) |
2 |
Included in 000a, 000b, or 000c |
|
007 |
175-8758
|
Connector |
1 |
Included in 000a, 000b, or 000c |
|
