# | Part | Description | Price | Req | Notes | Availability |
001 |
275-4735
|
Drive belt |
$35.09
|
2 |
|
usually ships 10-16 days |
002 |
275-4737
|
Sheave |
$114.07
|
2 |
|
usually ships 10-16 days |
003 |
175-8818
|
Square keyway |
$4.09
|
2 |
|
usually ships 10-16 days |
004 |
999-0497
|
Nut M6-1 nylon insert lock stainless steel |
$0.99
|
8 |
|
ships same day |
005 |
999-1041
|
Screw M6-1 x 12mm pan head phillips stainless steel |
$0.99
|
8 |
|
ships same day |
006 |
175-8819
|
Drive plug |
$55.88
|
2 |
|
ships same day |
007 |
275-4736
|
Screw M8-1.25 x 20mm hex washer head stainless steel SEMS |
$4.09
|
4 |
|
ships same day |
008 |
275-1489
|
KEY, SQ, 0.19 X 0.19, 0.50L (Tennant Industrial) |
$6.17
|
2 |
|
ships same day |
009 |
275-1492
|
Drive shaft |
$145.09
|
2 |
|
ships same day |
010 |
175-2471
|
Ball bearing |
$19.25
|
4 |
|
ships same day |
011 |
175-8820
|
Spacer |
$15.95
|
2 |
|
ships same day |
012 |
175-8821
|
Bearing housing |
$122.98
|
2 |
|
usually ships 10-16 days |
013 |
275-9683
|
Screw M8-1.25 x 210mm hex head |
$19.80
|
2 |
|
usually ships 1-5 days |
014 |
999-0496
|
Nut M8-1.25 nylon insert lock stainless steel |
$1.08
|
2 |
|
ships same day |
015a |
275-7482
|
Brush motor |
$1,121.12
|
2 |
(Includes 15b-16) |
usually ships 10-16 days |
015b |
275-5306
|
Carbon brush (pkg of 4) |
$101.53
|
1 |
|
ships same day |
016 |
175-4202
|
Square keyway |
$4.88
|
1 |
|
usually ships 10-16 days |
017 |
275-4738
|
Sheave |
$87.34
|
2 |
|
usually ships 10-16 days |
018 |
999-0431
|
Screw 8-32 x 1/4 set socket cup point alloy plain finish |
$0.99
|
4 |
|
ships same day |
019 |
999-0024
|
Washer 5/16 flat stainless steel |
$1.34
|
4 |
|
ships same day |
020 |
175-8677
|
Brush motor harness |
$33.66
|
2 |
|
usually ships 1-5 days |
021 |
999-1053
|
Washer 5/16 internal star lock stainless steel |
$0.99
|
4 |
|
ships same day |
022 |
999-1424
|
Nut M8-1.25 hex stainless steel |
$1.65
|
4 |
|
ships same day |
023 |
175-8682
|
Terminal boot (black) |
$5.28
|
2 |
|
usually ships 1-5 days |
024 |
175-8681
|
Terminal boot (red) (OBSOLETE) |
$1.85
|
2 |
|
usually ships 10-16 days |
025a |
175-2475
|
Idler plug assembly |
$109.56
|
2 |
(Includes 25-28) |
usually ships 10-16 days |
025b |
175-2478
|
Brush idler plug |
$28.93
|
1 |
|
ships same day |
026 |
175-2472
|
Retaining ring |
$3.04
|
1 |
|
usually ships 10-16 days |
027 |
175-2476
|
Idler plug shaft |
$74.69
|
1 |
|
usually ships 10-16 days |
028 |
175-2477
|
Roll pin |
$3.04
|
1 |
|
usually ships 10-16 days |
029 |
175-8824
|
Roller door |
$44.22
|
2 |
|
usually ships 10-16 days |
030 |
999-0120
|
Washer 3/8 SAE flat |
$0.99
|
2 |
|
ships same day |
031 |
175-4494
|
Washer M10 |
$4.09
|
2 |
|
usually ships 10-16 days |
032 |
175-2947
|
Bolt M10 x 1-1/2 x 16 hex head stainless steel |
$4.88
|
2 |
|
ships same day |
033 |
175-8825
|
Housing weldment |
$2,086.81
|
1 |
|
usually ships 10-16 days |
034 |
175-8826
|
Spacer |
$18.15
|
4 |
|
usually ships 10-16 days |
035 |
175-8827
|
Foam gasket |
$25.19
|
2 |
|
ships same day |
036 |
175-4292
|
Console gasket |
$18.15
|
2 |
|
ships same day |
037 |
175-8828
|
Belt cover |
$132.77
|
2 |
|
usually ships 10-16 days |
038 |
999-0016
|
Washer 1/4 flat plain finish |
$0.99
|
4 |
|
ships same day |
039 |
999-1383
|
Screw M6-1 x 16mm hex head stainless steel |
$3.96
|
8 |
|
ships same day |
040 |
175-8817
|
Belt kit (belts, square keyways and hardware) |
$157.96
|
2 |
|
usually ships 10-16 days |
041 |
175-2465
|
Drive sprocket |
$69.30
|
2 |
|
usually ships 10-16 days |
042 |
175-8816
|
Belt |
$90.42
|
2 |
|
usually ships 10-16 days |
043 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.99
|
2 |
|
ships same day |
044 |
175-4544
|
Washer M6 locking |
$4.09
|
2 |
|
ships same day |
045 |
999-0507
|
Bolt M6-1 x 16mm hex head full thread plain finish |
$0.99
|
2 |
|
ships same day |
046 |
999-0355
|
Washer 3/8 x 7/8 SAE flat stainless steel |
$0.99
|
2 |
|
ships same day |
