| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
175-6020
|
Braided hose 3/8 x 45 inch (gray) |
1 |
|
|
002 |
175-6081
|
Hose clamp |
1 |
|
|
003 |
175-2613
|
Straight brass fitting |
1 |
|
|
004a |
991-8158
|
1/4 inch BH2-60 female coupler (mate to QD40) |
1 |
|
|
004b |
175-7396
|
6 Jet spraybar assembly (OBSOLETE) |
1 |
|
|
005 |
991-8150
|
1/4 inch BH2-61 male nipple (mate to QD80) |
1 |
|
|
006 |
175-6244
|
Nipple |
1 |
|
|
007 |
175-3534
|
Elbow fitting 1/8 x 1/4 inch |
1 |
|
|
008 |
175-7397
|
6 Jet spray bar |
1 |
|
|
009 |
175-6121
|
Brass plug |
2 |
|
|
010 |
175-7398
|
1/8 Inch spray nozzle |
6 |
|
|
011 |
175-7399
|
Quick jet spray tip |
6 |
|
|
N/S |
175-7400
|
Front decal (OBSOLETE) |
1 |
|
|
