| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
375-0465
|
Relay plate (Tennant Industrial) |
1 |
|
|
2 |
375-0466
|
Relay box isolator (Tennant Industrial) |
2 |
|
|
3 |
999-0821
|
Bolt 1/4-20 x 1/2 hex head grade 9 yellow zinc |
4 |
|
|
4 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
7 |
|
|
5 |
999-0190
|
Nut 1/4-20 hex plain finish |
2 |
|
|
6 |
375-0467
|
Intake manifold (Tennant Industrial) |
1 |
|
|
7 |
375-0468
|
Intake manifold plug (Tennant Industrial) |
1 |
|
|
8 |
375-0494
|
Hole injector plug |
4 |
|
|
9 |
375-0469
|
Intake manifold plug fitting (Tennant Industrial) |
1 |
|
|
10 |
375-0470
|
Sensor port plug (Tennant Industrial) |
1 |
|
|
11 |
375-0471
|
12 npt plug stainless steel (Tennant Industrial) |
1 |
|
|
12 |
275-0113
|
HOSE, PVC, CLR, 0.38ID 0.56OD 022.0L (Tennant Industrial) |
1 |
|
|
13 |
375-0476
|
Throttle body intake adapter (Tennant Industrial) |
1 |
|
|
14 |
675-5159
|
VR, SENSOR, SPD, TIMING WHEEL [3.0L] (Tennant Industrial) |
1 |
|
|
15 |
999-0020
|
Bolt 1/4-20 x 3/4 hex head grade 5 zinc plated |
1 |
|
|
16 |
275-2140
|
SCREW, SOC, M6 X 1.00 X 25, 12.9 (Tennant Industrial) |
4 |
|
|
17 |
275-6686
|
FITTING, BRS, E90 (TENNANT INDUSTRIAL) |
1 |
|
|
18 |
675-6474
|
VR, THROTTLE BODY [MIT , BOSCH] (Tennant Industrial) |
1 |
|
|
19 |
375-0518
|
Mold hose (Tennant Industrial) |
1 |
|
|
20 |
375-0479
|
Vacuum fitting (Tennant Industrial) |
1 |
|
|
21 |
375-0495
|
400mm valve adapter (Tennant Industrial) |
1 |
|
|
22 |
175-6810
|
SCREW, SOC, M8 X 1.25 X 70, 12.9 (Tennant Industrial) |
4 |
|
|
23 |
375-0496
|
Bolt M5 x 80 x 35 socket head (Tennant Industrial) |
4 |
|
|
24 |
375-3531
|
Hose (Tennant Industrial) |
1 |
|
|
25 |
275-6571
|
Fuel mixer (Tennant Industrial) |
1 |
|
|
26 |
375-0497
|
E90 fitting (Tennant Industrial) |
1 |
|
|
27 |
999-0469
|
Nut M6-1 nylon insert lock zinc plated |
4 |
|
|
28 |
375-0505
|
Spring hose clamp (Tennant Industrial) |
1 |
|
|
29 |
375-0506
|
Hose (Tennant Industrial) |
1 |
|
|
30 |
375-0507
|
Hose cover (Tennant Industrial) |
1 |
|
|
31 |
375-0508
|
Spring hose clamp (Tennant Industrial) |
1 |
|
|
32 |
375-0509
|
Gas supply hose (Tennant Industrial) |
1 |
|
|
33 |
275-6104
|
VR, REGULATOR [EP] (Tennant Industrial) |
1 |
|
|
34 |
275-6105
|
VR, FITTING KIT [EPR] (Tennant Industrial) |
1 |
|
|
35 |
375-0510
|
Hose clamp (Tennant Industrial) |
1 |
|
|
36 |
375-0511
|
Hose (Tennant Industrial) |
1 |
|
|
37 |
175-0199
|
Hose clamp |
5 |
|
|
38 |
275-6647
|
Fitting |
1 |
|
|
39 |
375-0512
|
Nipple fitting (Tennant Industrial) |
1 |
|
|
40a |
375-3539
|
Fuel lock valve wire connector (Tennant Industrial) |
1 |
(includes 40b) |
|
40b |
375-0513
|
Gas fuelock filter kit (Tennant Industrial) |
1 |
|
|
41 |
375-0514
|
Isolator (Tennant Industrial) |
3 |
|
|
42 |
999-0665
|
Nut M8-1.25 flange lock |
3 |
|
|
43 |
375-0515
|
LPG regulator bracket weldment (Tennant Industrial) |
1 |
|
|
44 |
375-0516
|
Screw (Tennant Industrial) |
2 |
|
|
45 |
275-6674
|
Washer flat (TENNANT INDUSTRIAL) |
2 |
|
|
46 |
375-0482
|
Air bleed tube (Tennant Industrial) |
1 |
|
|
47 |
375-0483
|
Brass fitting (Tennant Industrial) |
1 |
|
|
48 |
175-6869
|
FITTING, DRAINCOCK, E90, .25NPT (Tennant Industrial) |
1 |
|
|
49 |
175-3594
|
Hose clamp |
1 |
|
|
50 |
275-7373
|
GASKET KIT, REPAIR, LPG [GM1.6L 2007] (Tennant Industrial) |
1 |
|
|
51 |
375-3785
|
Controller bracket (Tennant Industrial) |
1 |
|
|
52 |
175-0574
|
Bolt 6mm-1 x 35 hex head |
4 |
|
|
53 |
999-1133
|
Bolt M8-1.25 x 20mm hex head full thread plain |
2 |
|
|
54 |
999-0006
|
Washer 3/16 flat zinc plated |
8 |
|
|
55 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
2 |
|
|
56 |
375-3541
|
Module (Tennant Industrial) |
1 |
|
|
