| # | Part | Description |
Req | Notes | Availability |
|---|
2b |
991-3063
|
Oil filter |
1 |
|
|
3 |
999-0439
|
Nut M6-1 hex coarse thread |
1 |
|
|
6 |
375-3466
|
Hose end fitting (Tennant Industrial) |
2 |
|
|
8 |
575-1307
|
VR, PLUG, FLARE, 37DEG [MIT] (Tennant Industrial) |
1 |
|
|
9 |
999-0120
|
Washer 3/8 SAE flat |
3 |
|
|
12 |
375-0448
|
Repair plate kit (Tennant Industrial) |
1 |
|
|
14 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
4 |
|
|
15 |
999-0821
|
Bolt 1/4-20 x 1/2 hex head grade 9 yellow zinc |
4 |
|
|
16 |
375-0451
|
Screw 3/8-16 x 1 1/2 socket (Tennant Industrial) |
2 |
|
|
19 |
375-3783
|
Rear bracket (Tennant Industrial) |
1 |
|
|
20 |
175-6823
|
ISOLATOR, VIB, .50D (Tennant Industrial) |
3 |
|
|
21 |
175-3470
|
Washer .53b 1.88d .12 steel plated |
3 |
|
|
22 |
175-6824
|
Screw M12-1 3/4 x 60mm hex |
3 |
|
|
24 |
999-0519
|
Nut M12-1.75 nylon insert lock stainless steel |
3 |
|
|
25 |
999-0687
|
Bolt 1/2-13 x 1 1/4 hex head stainless steel |
2 |
|
|
28 |
375-0445
|
Position sensor (Tennant Industrial) |
1 |
|
|
29a |
375-3615
|
Oxygen sensor (Tennant Industrial) |
1 |
(between SN 007000 and SN 008999) |
|
32 |
275-7489
|
SENDER-TEMPERATURE, WATER (Tennant Industrial) |
1 |
|
|
33 |
375-0544
|
Plug pipe fitting (Tennant Industrial) |
1 |
(between SN 007000 and SN 008999) |
|
34 |
375-0461
|
M18 x 1.5 pipe fitting (Tennant Industrial) |
1 |
(after SN 008999) |
|
