| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
375-3823
|
Plate (Tennant Industrial) |
2 |
|
usually ships 16-21 days |
2 |
375-3824
|
Carb gasket (Tennant Industrial) |
1 |
|
usually ships 16-21 days |
3 |
999-1320
|
Screw M6-1 x 20mm socket head stainless steel |
2 |
|
usually ships 11-14 days |
4 |
375-3826
|
Solution hose (Tennant Industrial) |
1 |
|
usually ships 16-21 days |
5 |
175-3594
|
Hose clamp |
1 |
|
usually ships 16-21 days |
6 |
175-0199
|
Hose clamp |
1 |
|
usually ships 16-21 days |
7 |
375-3835
|
Ignition control (Tennant Industrial) |
1 |
(before SN 005504) |
usually ships 16-21 days |
8 |
375-0754
|
Vacuum hose (Tennant Industrial) |
1 |
|
usually ships 16-21 days |
9 |
175-2359
|
Plug |
1 |
|
usually ships 1-5 days |
10 |
375-3827
|
Actuator (Tennant Industrial) (OBSOLETE) |
1 |
|
usually ships 16-21 days |
11 |
N/A
|
Not available |
1 |
(bracket) |
usually ships 3-26 days |
12 |
375-3828
|
Linkage kit (Tennant Industrial) |
1 |
|
usually ships 16-21 days |
13 |
375-3829
|
Actuator strap (Tennant Industrial) |
1 |
|
usually ships 16-21 days |
14 |
375-3777
|
E90 fitting (Tennant Industrial) |
1 |
|
usually ships 16-21 days |
15 |
375-3778
|
Carburetor with gasket (Tennant Industrial) |
1 |
(includes 16-19a) |
usually ships 16-21 days |
16 |
375-3824
|
Carb gasket (Tennant Industrial) |
1 |
|
usually ships 16-21 days |
17 |
375-3779
|
Carb fitting (Tennant Industrial) |
1 |
|
usually ships 16-21 days |
18 |
375-3545
|
Fitting (Tennant Industrial) |
1 |
|
usually ships 16-21 days |
19a |
375-3830
|
Control kit (Tennant Industrial) |
1 |
(includes 19b) |
usually ships 16-21 days |
19b |
375-3809
|
Control box plug kit (tennant industrial) |
2 |
(after SN 005817) |
usually ships 16-21 days |
20 |
375-3831
|
Control module (Tennant Industrial) |
1 |
(after SN 005503) |
usually ships 16-21 days |
21 |
375-3832
|
Sensor bracket (Tennant Industrial) |
1 |
(after SN 005503) |
usually ships 16-21 days |
22 |
375-3833
|
Sensor (Tennant Industrial) |
1 |
(after SN 005503) |
usually ships 16-21 days |
23 |
175-3219
|
SCREW, PAN, PHL, M6 X 1.00 X 25, 4.8 (Tennant Industrial) |
3 |
(after SN 005503) |
usually ships 1-5 days |
24 |
175-6758
|
Screw M6-1 x 30mm hex head |
2 |
(after SN 005503) |
usually ships 16-21 days |
25 |
999-0006
|
Washer 3/16 flat zinc plated |
2 |
(after SN 005503) |
usually ships 11-14 days |
26 |
999-0469
|
Nut M6-1 nylon insert lock zinc plated |
5 |
(after SN 005503) |
usually ships 11-14 days |
27a |
375-3780
|
Governor assembly ford 1.3 LPG (Tennant Industrial) |
1 |
(includes 10-19a and 27b) |
usually ships 16-21 days |
27b |
375-3781
|
Governor LPG (Tennant Industrial) |
1 |
(includes 10-14) |
usually ships 16-21 days |
