| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
275-8091
|
Steering control assembly |
$1,144.40
|
1 |
|
ships same day |
2 |
175-3200
|
Square keyway |
$3.00
|
1 |
|
ships same day |
3 |
999-0499
|
Bolt M8-1.25 x 20mm hex head full thread stainless steel |
$1.85
|
4 |
|
ships same day |
4 |
999-9097
|
Washer M8 flat stainless steel |
$0.99
|
4 |
|
ships same day |
5 |
275-8095
|
Nylon strap |
$18.40
|
1 |
|
ships same day |
6 |
275-8094
|
3 foot nylon sleeve |
$35.10
|
1 |
|
usually ships 5-16 days |
7 |
175-2202
|
Nylon wire tie |
$3.00
|
2 |
|
ships same day |
8 |
175-3179
|
P clamp |
$3.60
|
2 |
|
usually ships 5-16 days |
9 |
999-1383
|
Screw M6-1 x 16mm hex head stainless steel |
$0.99
|
2 |
|
ships same day |
10 |
999-0006
|
Washer 3/16 flat zinc plated |
$0.99
|
2 |
|
ships same day |
11 |
275-9654
|
Complete drive and gearbox assembly |
$4,165.80
|
1 |
(includes 12) |
usually ships 5-16 days |
12a |
175-8753
|
Female connector |
$6.80
|
1 |
|
ships same day |
12b |
175-8756
|
Male and female secondary lock |
$3.60
|
1 |
|
usually ships 5-16 days |
12c |
275-8096
|
Female terminal |
$3.00
|
2 |
|
ships same day |
12d |
275-8097
|
Wire seal |
$3.10
|
2 |
|
ships same day |
