| # | Part | Description | Price | Req | Notes | Availability |
|---|
1a |
275-8082
|
Left instrument panel |
$207.02
|
1 |
(standard) |
ships same day |
1b |
275-9347
|
Left instrument panel |
$251.02
|
1 |
(ec-h20) |
usually ships 1-5 days |
2 |
275-8083
|
Instrument panel cover |
$4.29
|
1 |
|
usually ships 5-16 days |
3 |
275-8084
|
Pivot block |
$3.30
|
2 |
|
usually ships 5-16 days |
4 |
275-9348
|
Left hand panel gasket |
$5.85
|
1 |
|
ships same day |
5a |
275-9349
|
Right hand instrument panel |
$45.76
|
1 |
(after SN 10403818) |
usually ships 1-5 days |
5b |
275-8088
|
Key switch kit |
$77.88
|
1 |
(before SN 10403819) |
ships same day |
6 |
275-8087
|
Right hand panel gasket |
$5.28
|
1 |
|
usually ships 1-5 days |
7 |
275-1411
|
Plastic rivet |
$3.96
|
10 |
|
ships same day |
8a |
275-8088
|
Key switch kit |
$77.88
|
1 |
(before SN 10403819) (includes 9a) |
ships same day |
8b |
175-7872
|
Key switch with 2 keys |
$53.13
|
1 |
(after SN 10403818) (includes 9b) |
ships same day |
8c |
991-5161
|
Key switch with key and ring |
$16.04
|
1 |
(NON-OEM) |
ships same day |
9a |
175-3215
|
Key (sold individually) |
$13.97
|
1 |
(before SN 10403819) |
ships same day |
9b |
991-1634
|
Key (pkg of 2) |
$10.67
|
1 |
(after SN 10403818) |
ships same day |
10a |
275-7033
|
Rocker switch |
$32.89
|
1 |
(OEM) (direction) |
ships same day |
10b |
991-5145
|
Rocker switch |
$20.98
|
1 |
(NON-OEM) (direction) |
ships same day |
11 |
275-1416
|
Safety shut-off switch |
$40.01
|
1 |
|
ships same day |
12a |
275-5324
|
Steering column with decal |
$497.86
|
1 |
(Nobles) |
usually ships 1-5 days |
12b |
275-5325
|
Steering column with decal |
$262.35
|
1 |
(SSR ec-H2O) |
usually ships 1-5 days |
13 |
999-9082
|
Screw M8-1.25 x 25mm hex head stainless steel |
$1.85
|
4 |
|
ships same day |
14 |
275-4715
|
LED light |
$100.21
|
1 |
|
ships same day |
15 |
275-9354
|
Horn switch |
$34.76
|
1 |
|
ships same day |
