| # | Part | Description | Price | Req | Notes | Availability |
|---|
1a |
275-9259
|
Frame weldment |
$1,917.30
|
1 |
(28 inch) (after SN 10448498) |
usually ships 1-5 days |
1b |
275-9262
|
Frame weldment (OBSOLETE) |
$1,220.89
|
1 |
(32 inch) (after SN 10448498) |
usually ships 10-16 days |
2 |
999-0114
|
Washer 1/2 SAE flat |
$0.99
|
2 |
(32 inch) |
ships same day |
3 |
999-1383
|
Screw M6-1 x 16mm hex head stainless steel |
$3.96
|
1 |
(after SN 10448498) |
ships same day |
4 |
999-1653
|
Screw M8-1.25 x 30mm hex head stainless steel |
$4.36
|
1 |
(after SN 10448498) |
ships same day |
5 |
175-2366
|
Rubber grommet |
$6.49
|
1 |
|
ships same day |
6 |
275-9261
|
Static strip with grommet |
$28.16
|
1 |
|
usually ships 10-16 days |
7 |
275-8059
|
Tire assembly |
$224.40
|
2 |
|
ships same day |
8 |
175-3294
|
Retaining ring |
$3.30
|
2 |
|
ships same day |
9 |
275-8060
|
Cap |
$8.14
|
2 |
|
ships same day |
10 |
175-2202
|
Nylon wire tie |
$4.49
|
4 |
|
ships same day |
11a |
175-2667
|
P clamp |
$5.28
|
1 |
(after SN 10518138) |
usually ships 10-16 days |
11b |
175-3170
|
P clamp |
$4.22
|
1 |
(before SN 10518139) |
usually ships 1-5 days |
12 |
999-1312
|
Screw M6-1 x 20mm hex head stainless steel |
$0.99
|
1 |
|
ships same day |
13 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.99
|
1 |
|
ships same day |
14 |
999-0497
|
Nut M6-1 nylon insert lock stainless steel |
$0.99
|
1 |
|
ships same day |
15 |
275-8062
|
Horn |
$160.05
|
1 |
|
usually ships 10-16 days |
16 |
275-9260
|
Horn mounting plate |
$9.13
|
1 |
|
usually ships 1-5 days |
17 |
275-8369
|
PIN, CLEVIS, 0.50D X 4.00L (Tennant Industrial) |
$21.67
|
2 |
(32 inch) |
usually ships 1-5 days |
18 |
175-2512
|
Bumper roller |
$16.50
|
2 |
(32 inch) |
usually ships 10-16 days |
19 |
999-0497
|
Nut M6-1 nylon insert lock stainless steel |
$0.99
|
4 |
(32 inch) |
ships same day |
20 |
175-2040
|
Cotter pin |
$3.30
|
2 |
(32 inch) |
usually ships 10-16 days |
21 |
275-9323
|
Left guard bracket |
$122.32
|
1 |
(32 inch) |
ships same day |
22 |
275-9324
|
Right guard bracket |
$122.32
|
1 |
(32 inch) |
ships same day |
23 |
999-1312
|
Screw M6-1 x 20mm hex head stainless steel |
$0.99
|
4 |
(32 inch) |
ships same day |
24 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.99
|
8 |
(32 inch) |
ships same day |
N/S |
999-0499
|
Bolt M8-1.25 x 20mm hex head full thread stainless steel |
$1.85
|
7 |
(before SN 10448499) |
ships same day |
N/S |
999-0507
|
Bolt M6-1 x 16mm hex head full thread plain finish |
$0.99
|
1 |
(before SN 10448499) |
ships same day |
N/S |
175-4544
|
Washer M6 locking |
$4.49
|
1 |
(before SN 10448499) |
ships same day |
N/S |
999-0355
|
Washer 3/8 x 7/8 SAE flat stainless steel |
$0.99
|
7 |
(before SN 10448499) |
ships same day |
