SCOUT 37B Motor and Drive Wheel Assembly

#PartDescriptionPriceReqNotesAvailability
1a 175-9066 Replacement motor kit $948.00 1 (includes 1c) usually ships 1-5 days
1b 175-9068 24 Volt 3/4 HP 2100 RPM Electric motor $1,155.60 1 (includes 1d-1g) usually ships 1-5 days
1c N/A Not available Call for price 1 Motor brush set usually ships 3-26 days
1d 175-9201 Brush kit $64.30 1 usually ships 5-16 days
1e 175-9070 Brush holder with brushes $113.00 1 usually ships 1-5 days
1f 175-9071 Ball bearing 43/64 x 1-37/64 x 15/32 $16.30 1 usually ships 1-5 days
1g 175-9072 Ball bearing $8.58 1 ships same day
2 175-8818 Square keyway $3.00 1 ships same day
3 N/A Not available Call for price 1 Motor mounting bracket usually ships 3-26 days
4 175-9075 Sheave $80.30 1 usually ships 1-5 days
5 175-9076 V-belt $29.90 1 usually ships 5-16 days
6 175-9077 Sheave $84.60 1 usually ships 1-5 days
7 175-9078 Sheave $51.40 1 usually ships 1-5 days
8 175-2305 Washer $3.60 4 ships same day
9 175-9079 Bearing flange $11.90 4 usually ships 1-5 days
10 175-9080 Bearing with collar $54.20 2 usually ships 5-16 days
11 175-9081 Woodruff key $2.20 1 usually ships 1-5 days
12 175-9082 Shaft replacement kit (OBSOLETE) $190.40 1 (includes 13) usually ships 5-16 days
13 999-0562 Bolt 3/8-16 x 1 hex head stainless steel $1.50 1 ships same day
14 175-9083 Sheave $34.13 1 usually ships 1-5 days
15 175-9084 Clutch propel bracket weldment $22.20 1 usually ships 1-5 days
16 175-9085 PIN, CLEVIS, 0.37D X 0.62L (Tennant Industrial) $8.85 1 ships same day
17 175-9086 Arm clutch replacement kit $22.30 1 usually ships 1-5 days
18 175-9087 Flange bushing $4.60 2 usually ships 1-5 days
19 175-9088 Clutch control shaft $64.50 1 usually ships 1-5 days
20 175-9089 BRACKET WLDT, MOTOR [OHIO] (Tennant Industrial) $126.09 1 usually ships 1-5 days
21 175-9091 Right hand clutch propel arm idler $21.00 1 usually ships 1-5 days
22 175-9092 Flat sheave 1-13/16 x 1-3/8 x 43/64 $39.60 1 usually ships 1-5 days
23 999-0024 Washer 5/16 flat stainless steel $1.34 7 ships same day
24 175-9093 Bolt 3/8-16 x 2 cariage $3.00 1 usually ships 1-5 days
25 175-9094 Ball bearing $13.30 2 usually ships 5-16 days
26 175-9095 Sleeve $23.30 2 usually ships 1-5 days
27 175-9096 Idler replacement kit (OBSOLETE) $45.80 1 usually ships 5-16 days
28 175-9097 Bearing replacement kit $61.10 2 usually ships 1-5 days
29 175-9098 Basic retaining ring (Tennant Industrial) $4.84 1 usually ships 5-16 days
30 175-2122 90 degree cable boot $3.60 1 usually ships 5-16 days
31 175-9095 Sleeve $23.30 2 usually ships 1-5 days
32 175-9094 Ball bearing $13.30 2 usually ships 5-16 days
33 175-9102 Solid tire assembly (OBSOLETE) $469.80 1 usually ships 5-16 days
34 175-9103 Steel tube $23.30 1 usually ships 1-5 days
35 175-9104 Screw 1/2 - 13 x 6-1/2 hex $6.00 1 usually ships 1-5 days
36 999-0114 Washer 1/2 SAE flat $0.99 4 ships same day
37 175-9105 V-Belt $55.60 1 usually ships 5-16 days
38 175-9106 Left hand clutch propel arm $19.30 1 usually ships 1-5 days
39 175-9107 Bolt 3/8-16 x 1 carriage $2.90 1 usually ships 1-5 days
40 175-9066 Replacement motor kit $948.00 1 (order 175-9074 for only bracket replacement) usually ships 1-5 days
41 175-9090 ARM ASSY, CLUTCH, PROPEL, [140] (Tennant Industrial) $104.88 1 (includes 21-24) usually ships 1-5 days
42 175-9099 Solid tire assembly $546.50 1 (includes 31-36) usually ships 1-5 days
