| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
175-7118
|
DAMPER WLDT, FLOW (Tennant Industrial) |
1 |
|
|
002 |
175-7119
|
BUSHING, FLNG, 0.75B 0.81D 0.75L, NYL (Tennant Industrial) |
2 |
|
|
003 |
175-7120
|
Screw M8 x 1.25 x 50mm hex |
1 |
|
|
004 |
999-0024
|
Washer 5/16 flat stainless steel |
2 |
|
|
005 |
999-0471
|
Nut M8-1.25 nylon insert lock zinc plated |
2 |
|
|
006a |
175-7121
|
PLATE, DAMPER (Tennant Industrial) |
1 |
|
|
006b |
175-7122
|
SHAFT KIT, DAMPER, REPAIR (Tennant Industrial) |
1 |
|
|
007 |
175-7123
|
WASHER, FLAT, 0.59B 1.00D .12, SS [409] (Tennant Industrial |
1 |
|
|
008 |
175-7124
|
Damper shaft |
1 |
|
|
009 |
175-7125
|
SLEEVE, P/M, 0.32B 0.50D 0.1L [430SS] (Tennant Industrial) |
1 |
|
|
010 |
175-7126
|
LINK, DAMPER (Tennant Industrial) |
1 |
|
|
011 |
175-7127
|
ARM, LINK, .19 2.6L SLOT /0.4H (Tennant Industrial) |
1 |
|
|
012 |
175-7128
|
ARM WLDT, DAMPER (Tennant Industrial) |
1 |
|
|
013 |
999-1133
|
Bolt M8-1.25 x 20mm hex head full thread plain |
1 |
|
|
014 |
275-4699
|
Paper filter bags (package of 10) |
1 |
|
|
015 |
175-0024
|
Bag housing screen (OBSOLETE) |
2 |
|
|
016 |
999-0471
|
Nut M8-1.25 nylon insert lock zinc plated |
2 |
|
|
017 |
175-7129
|
Tension spring |
1 |
|
|
018 |
999-1228
|
Screw M5-.8 x 10mm hex head stainless steel |
2 |
|
|
019 |
999-1625
|
Nut M10-1.5 hex jam stainless steel |
2 |
|
|
020 |
175-7131
|
HANDLE, CNTRL, DAMPER (Tennant Industrial) |
1 |
|
|
021 |
175-7132
|
Thermostat switch |
1 |
|
|
022 |
999-0016
|
Washer 1/4 flat plain finish |
1 |
|
|
023 |
175-2263
|
Sleeve |
1 |
|
|
024 |
999-0581
|
Bolt M8-1.25 x 25mm hex head full thread zinc |
1 |
|
|
