| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
175-6999
|
HOPPER [LITTER HAWK] (Tennant Industrial) |
1 |
|
|
002 |
175-7000
|
PLUG, EXPANDABLE, RND 0.750H 0.7L (Tennant Industrial) |
1 |
|
|
003 |
175-7080
|
RETAINER, CANISTER (Tennant Industrial) |
2 |
|
|
004 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
4 |
|
|
005 |
999-0469
|
Nut M6-1 nylon insert lock zinc plated |
12 |
|
|
006 |
175-7081
|
HANDLE, CONTAINER, REAR (Tennant Industrial) |
1 |
|
|
007 |
175-7082
|
PLATE, BACKING, HANDLE (Tennant Industrial) |
1 |
|
|
008 |
175-7083
|
HANDLE, CONTAINER (Tennant Industrial) |
1 |
|
|
009 |
N/A
|
Not available |
1 |
(Bag liner) |
|
010 |
175-7085
|
BRACKET, HINGE, RH (Tennant Industrial) |
1 |
|
|
011 |
175-7086
|
BRACKET, HINGE, LH (Tennant Industrial) (OBSOLETE) |
1 |
|
|
012 |
275-4699
|
Paper filter bags (package of 10) |
8 |
|
|
013 |
175-3229
|
Screw 6mm-1 x 16 pan head |
2 |
|
|
014 |
175-7087
|
Container guide (Tennant Industrial) (OBSOLETE) |
2 |
|
|
015 |
175-7088
|
LINK, LIFT (Tennant Industrial) (OBSOLETE) |
2 |
|
|
016 |
175-7089
|
HANDLE WLDT, LIFT, HPPR (Tennant Industrial) (OBSOLETE) |
1 |
|
|
017 |
175-3274
|
Screw M6-1 x 16mm flat |
2 |
|
|
018 |
999-0016
|
Washer 1/4 flat plain finish |
4 |
|
|
019 |
999-0502
|
Bolt M6-1 x 20mm hex head full thread zinc |
2 |
|
|
020 |
175-5911
|
Handle grip sleeve |
3 |
|
|
021 |
175-2894
|
Nut M5-.8 hex nylon locking |
3 |
|
|
022 |
175-7090
|
CHAIN, SASH, 35, 06.0L 11 LINK (Tennant Industrial) |
1 |
|
|
023 |
175-2129
|
Rivet 1/8 x 5/16 x 1/4 blind steel |
1 |
|
|
024a |
175-3223
|
Screw 12-16 x 1/2 pan head plastic |
1 |
|
|
024b |
175-7092
|
BAG, ROLL [POLY, 15 BAG] (Tennant Industrial) |
1 |
|
|
025 |
175-7092
|
BAG, ROLL [POLY, 15 BAG] (Tennant Industrial) |
6 |
|
|
026 |
175-7093
|
PLATE, SPPT, HPPR (Tennant Industrial) |
2 |
|
|
027 |
999-0778
|
Screw M6-1 x 10mm hex head |
6 |
|
|
028 |
999-0471
|
Nut M8-1.25 nylon insert lock zinc plated |
4 |
|
|
029 |
999-0024
|
Washer 5/16 flat stainless steel |
4 |
|
|
