| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
175-6867
|
RADIATOR (Tennant Industrial) (OBSOLETE) |
1 |
|
|
002 |
175-6868
|
Radiator cap (OBSOLETE) |
1 |
|
|
003 |
175-6869
|
FITTING, DRAINCOCK, E90, .25NPT (Tennant Industrial) |
1 |
|
|
004 |
175-6970
|
IMPELLER (Tennant Industrial) (OBSOLETE) |
4 |
|
|
005 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
4 |
|
|
006 |
175-6871
|
HOSE, COOLANT, MOLD, 1.00ID TO 1.00ID (Tennant Industrial) |
1 |
|
|
007 |
175-6872
|
HOSE, COOLANT, MOLD, 1.00ID TO 1.00ID (Tennant Industrial) |
1 |
|
|
008 |
175-2254
|
Hose clamp |
4 |
|
|
009 |
175-6873
|
SHROUD KIT, RADIATOR (Tennant Industrial) (OBSOLETE) |
1 |
|
|
010 |
175-6874
|
PLATE, SHRD, RADIATOR (Tennant Industrial) |
1 |
|
|
011 |
175-6875
|
SHROUD, RADIATOR, RH (Tennant Industrial) (OBSOLETE) |
1 |
|
|
012 |
175-6876
|
SHROUD, RADIATOR, LH (Tennant Industrial) (OBSOLETE) |
1 |
|
|
013 |
175-6877
|
NUT, U, M6 X 1.00 (Tennant Industrial) |
7 |
|
|
014 |
999-1154
|
Bolt M8-1.25 x 12mm hex head cap brass |
12 |
|
|
015 |
999-0502
|
Bolt M6-1 x 20mm hex head full thread zinc |
4 |
|
|
016 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
16 |
|
|
017 |
175-6878
|
TANK, RECVY, COOLANT, 1.0QT (Tennant Industrial) |
1 |
|
|
018 |
175-6879
|
Elbow fitting |
2 |
|
|
019 |
999-1133
|
Bolt M8-1.25 x 20mm hex head full thread plain |
2 |
|
|
020 |
999-0665
|
Nut M8-1.25 flange lock |
2 |
|
|
021 |
999-0024
|
Washer 5/16 flat stainless steel |
2 |
|
|
022 |
175-5943
|
CLIP, SNAP-IN, 0.25H 0.80L, BLK NYL (Tennant Industrial) |
4 |
|
|
023 |
175-6880
|
BRACKET, MTG, TANK, COOLANT, F/87972 (Tennant Industrial) |
1 |
|
|
024 |
175-6881
|
SLEEVE, NYL, 1.63ID 35.0L (Tennant Industrial) |
1 |
|
|
025 |
175-6882
|
FLAP, AIR (Tennant Industrial) (OBSOLETE) |
1 |
|
|
026 |
999-0469
|
Nut M6-1 nylon insert lock zinc plated |
2 |
|
|
027 |
175-6883
|
Hydraulic cooler (Tennant Industrial) (OBSOLETE) |
1 |
|
|
