| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
175-6847
|
TANK, FUEL, 04.0GAL, 06.87W 10.2HI 13.3L (Tennant Industria |
1 |
|
|
002 |
175-6848
|
SEND-UNIT, FUEL, 90OHM, 09.4DEEP (Tennant Industrial) |
1 |
|
|
003 |
175-6849
|
GASKET, CORK, .13, 1.62ID 2.69OD (Tennant Industrial) |
1 |
|
|
004 |
175-6850
|
CAP, TANK, FUEL, 2.3NECK 2.6D (Tennant Industrial) |
1 |
|
|
005 |
999-0120
|
Washer 3/8 SAE flat |
2 |
|
|
006 |
175-6851
|
FITTING, BRS, E90, BM03/PM02 (Tennant Industrial) |
1 |
|
|
007 |
175-6852
|
STRAP WLDT, TANK, FUEL (Tennant Industrial) (OBSOLETE) |
2 |
|
|
008 |
N/A
|
Not available |
2 |
Nut |
|
009 |
675-9930
|
PUMP, FUEL (Tennant Industrial) |
1 |
|
|
010 |
175-6855
|
FITTING, BRS, STR, BM05/PM02 (Tennant Industrial) |
1 |
|
|
011 |
999-0502
|
Bolt M6-1 x 20mm hex head full thread zinc |
4 |
|
|
012 |
999-0016
|
Washer 1/4 flat plain finish |
4 |
|
|
013 |
999-6694
|
Nut M6-1 hex serrated flange stainless steel |
4 |
|
|
014 |
175-6856
|
HOSE, RBR, 0.19ID 0.41OD 37.0L (Tennant Industrial) |
1 |
|
|
015 |
175-3594
|
Hose clamp |
6 |
|
|
016 |
175-6857
|
FITTING, BRS, E90, IF05/PM04 (Tennant Industrial) |
3 |
|
|
017 |
175-6858
|
FUELLINE, DSL (Tennant Industrial) |
1 |
|
|
018 |
175-6859
|
FUELLINE, TANK TO PUMP [PLV4100] (Tennant Industrial) |
1 |
|
|
019 |
175-5951
|
COVER, BLU (Tennant Industrial) |
2 |
|
|
020 |
175-6860
|
FITTING, BRS, E90, IF05/PM02 (Tennant Industrial) |
1 |
|
|
021a |
175-6861
|
Fuel filter (Tennant Industrial) |
1 |
|
|
021b |
275-6392
|
Filter element (Tennant Industrial) |
1 |
|
|
022 |
175-6863
|
Straight brass fitting |
1 |
|
|
023 |
175-6864
|
FITTING, BANJO, FUEL (Tennant Industrial) |
1 |
|
|
024 |
175-6865
|
HOSE, 0050, 04, IF05STR / IM05STR, 10.0 (Tennant Industrial |
1 |
|
|
025 |
175-6866
|
FUELLINE, .31D 05IF/05IF 03.1L, STL (Tennant Industrial) |
1 |
|
|
