| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
175-6759
|
BRACKET WLDT, STEERING (Tennant Industrial) (OBSOLETE) |
1 |
|
|
002 |
999-0783
|
Screw M8-1.25 x 16mm hex head |
7 |
|
|
003 |
999-0024
|
Washer 5/16 flat stainless steel |
10 |
|
|
004 |
175-6760
|
MOUNT WLDT, BRG (Tennant Industrial) |
1 |
|
|
005 |
175-6761
|
Ball bearing (Tennant Industrial) (OBSOLETE) |
2 |
|
|
006 |
175-6762
|
CHANNEL WLDT, STEERING (Tennant Industrial) (OBSOLETE) |
1 |
|
|
007 |
175-3195
|
Ball bearing |
2 |
|
|
008 |
175-6763
|
JOINT, UNIVERSAL (Tennant Industrial) (OBSOLETE) |
1 |
|
|
009 |
999-0104
|
Screw 5/16-18 x 1/2 socket head alloy plain finish |
4 |
|
|
010 |
175-6764
|
SHAFT WLDT, STEERING, REAR (Tennant Industrial) (OBSOLETE) |
1 |
|
|
011 |
175-6744
|
RING, RETAINING, EXT, 0.98D, BASIC (Tennant Industrial) |
1 |
|
|
012 |
175-6746
|
Woodruff key |
1 |
|
|
013 |
175-6765
|
ARM WLDT, STEERING, REAR (Tennant Industrial) (OBSOLETE) |
1 |
|
|
014 |
175-6766
|
RING, RETAINING, EXT, 0.75D (Tennant Industrial) |
1 |
|
|
015 |
175-5356
|
Square keyway |
1 |
|
|
016 |
175-6767
|
Rear steering rod (Tennant Industrial) (OBSOLETE) |
1 |
|
|
017 |
999-0134
|
Nut 1/2-20 hex jam plain finish |
2 |
|
|
018 |
175-6748
|
ROD-END, 0.50-20RH FEM 0.50B (Tennant Industrial) |
1 |
|
|
019 |
999-0262
|
Nut 1/2-13 nylon insert jam lock zinc plated |
1 |
|
|
020 |
175-6749
|
ROD-END, 0.50-20LH FEM 0.50-20STUD (Tennant Industrial) |
1 |
|
|
021 |
175-6750
|
NUT, HEX, LOCK, .50-20, NL, THIN (Tennant Industrial) |
1 |
|
|
022 |
175-0581
|
Sprocket |
3 |
|
|
023 |
999-0665
|
Nut M8-1.25 flange lock |
3 |
|
|
024 |
175-6768
|
P clamp (Tennant Industrial) |
1 |
|
|
