| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
175-6731
|
BRACKET WLDT, MTG, STEERING (Tennant Industrial) (OBSOLETE) |
1 |
|
|
002 |
175-6732
|
BRACKET WLDT, STEERING (Tennant Industrial) (OBSOLETE) |
1 |
|
|
003 |
999-1622
|
Screw M8-1.25 x 25mm flat head phillips stainless steel |
2 |
|
|
004 |
999-0024
|
Washer 5/16 flat stainless steel |
2 |
|
|
005 |
999-0471
|
Nut M8-1.25 nylon insert lock zinc plated |
2 |
|
|
006 |
999-1133
|
Bolt M8-1.25 x 20mm hex head full thread plain |
4 |
|
|
007 |
175-6733
|
Steering coupling (OBSOLETE) |
1 |
|
|
008a |
175-6734
|
COVER, STEERING, BLU (Tennant Industrial) (OBSOLETE) |
1 |
|
|
008b |
175-6735
|
COVER, STEERING (Tennant Industrial) (OBSOLETE) |
1 |
|
|
009 |
175-5943
|
CLIP, SNAP-IN, 0.25H 0.80L, BLK NYL (Tennant Industrial) |
6 |
|
|
010 |
175-3220
|
Push switch |
1 |
|
|
011 |
175-3221
|
Switch contact |
1 |
|
|
012 |
175-5910
|
SWITCH, SNAP, 15A NO, RLR (Tennant Industrial) |
2 |
|
|
013 |
999-1225
|
Screw M5-.8 x 12mm pan head phillips zinc |
2 |
|
|
014 |
999-0006
|
Washer 3/16 flat zinc plated |
4 |
|
|
015 |
999-0740
|
Nut M5-.8 hex stainless steel |
2 |
|
|
016 |
175-3163
|
Screw M8-1.25 x 60mm hex head |
2 |
|
|
017 |
175-0123
|
Indicator light decal (OBSOLETE) |
4 |
|
|
018 |
999-0569
|
Screw 10 x 1/2 pan head phillips sheet metal |
2 |
|
|
019 |
175-6736
|
Insulation (Tennant Industrial) (OBSOLETE) |
1 |
|
|
020 |
175-6737
|
Insulation (Tennant Industrial) (OBSOLETE) |
1 |
|
|
021 |
175-6738
|
SWITCH, PUSH [HORN] (Tennant Industrial) |
1 |
|
|
022 |
175-6739
|
PLATE, MTG, SWITCH (Tennant Industrial) (OBSOLETE) |
1 |
|
|
023 |
175-6740
|
SPACER (Tennant Industrial) (OBSOLETE) |
2 |
|
|
024 |
175-6741
|
PLUG, HOLE, RND, 1.00H .00-.17, BLK NYL (Tennant Industrial |
2 |
|
|
