| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
175-5982
|
PLATE, COVER, RH W/LABEL (Tennant Industrial) (OBSOLETE) |
1 |
With label |
|
002 |
175-5990
|
PLATE, COVER, LH (Tennant Industrial) (OBSOLETE) |
1 |
|
|
003 |
175-5983
|
SHIELD, LH (Tennant Industrial) (OBSOLETE) |
1 |
|
|
004 |
175-5984
|
SHIELD, RH (Tennant Industrial) (OBSOLETE) |
1 |
|
|
005 |
999-1133
|
Bolt M8-1.25 x 20mm hex head full thread plain |
12 |
|
|
006 |
999-0024
|
Washer 5/16 flat stainless steel |
10 |
|
|
007 |
175-8448
|
CATCH, COVER (Tennant Industrial) (OBSOLETE) |
2 |
|
|
008 |
175-0755
|
Sleeve |
2 |
|
|
009 |
175-5971
|
Plastic rivet |
6 |
|
|
010 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
4 |
|
|
011 |
175-5985
|
SEAL, COVER (Tennant Industrial) (OBSOLETE) |
2 |
|
|
012 |
175-5943
|
CLIP, SNAP-IN, 0.25H 0.80L, BLK NYL (Tennant Industrial) |
16 |
|
|
013 |
175-5986
|
BRACKET WLDT, HINGE, COVER, FRONT (Tennant Industrial) |
1 |
|
|
014 |
175-5987
|
FLAP, ACCESS (Tennant Industrial) (OBSOLETE) |
1 |
|
|
015 |
175-5988
|
Washer 13/64 x 1/2 x 5/8 |
3 |
|
|
016 |
175-5989
|
PLATE, COVER, LH (Tennant Industrial) |
1 |
|
|
017 |
175-5957
|
Pop rivet 3/16 x 49/69 x 38dhd |
3 |
|
|
