| # | Part | Description |
Req | Notes | Availability |
|---|
001a |
175-8150
|
VALVE, WATER, FLOW CNTRL, HOSE ADAPTER (Tennant Industrial) |
1 |
|
|
001b |
175-6718
|
Front cover kit (yellow) (Tennant Industrial) (OBSOLETE) |
1 |
|
|
002 |
375-4362
|
8 foot bulb seal (Tennant Industrial) |
1 |
|
|
003 |
175-6719
|
LIGHT, STROBE, AMB (Tennant Industrial) |
1 |
|
|
004 |
175-6720
|
BRACKET WLDT, MTG, STROBE (Tennant Industrial) |
1 |
|
|
005 |
999-0377
|
Washer 6 SAE flat plain finish |
2 |
|
|
006 |
175-6721
|
SCREW, CHZ, M4 X 0.7, 60, 4.8, PL (Tennant Industrial) |
2 |
|
|
007 |
999-0954
|
Nut M4-.7 nylon insert lock stainless steel |
2 |
|
|
008 |
175-4924
|
HANDLE, HOOD (Tennant Industrial) |
1 |
|
|
009 |
175-5139
|
SCREW, PAN, PHL, M5 X 0.80 X 25, 4.8 (Tennant Industrial) |
2 |
|
|
010 |
999-0006
|
Washer 3/16 flat zinc plated |
4 |
|
|
011 |
175-2894
|
Nut M5-.8 hex nylon locking |
4 |
|
|
012 |
175-5196
|
HINGE WLDT, HOOD (Tennant Industrial) |
1 |
|
|
013 |
175-5197
|
ARM WLDT, LATCH, RH (Tennant Industrial) |
1 |
|
|
014 |
175-5198
|
SPRING, COIL (Tennant Industrial) |
1 |
|
|
015 |
175-5199
|
ARM WLDT, LATCH, LH (Tennant Industrial) |
1 |
|
|
016 |
175-5909
|
PLATE, ROD, PROP (Tennant Industrial) |
1 |
|
|
017 |
175-5910
|
SWITCH, SNAP, 15A NO, RLR (Tennant Industrial) |
1 |
|
|
018 |
175-5911
|
Handle grip sleeve |
2 |
|
|
019 |
999-0581
|
Bolt M8-1.25 x 25mm hex head full thread zinc |
1 |
|
|
020 |
175-2298
|
Washer .38 x .06 stainless steel |
1 |
|
|
021 |
175-6176
|
Cotter pin |
1 |
|
|
022 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
13 |
|
|
023 |
999-0471
|
Nut M8-1.25 nylon insert lock zinc plated |
8 |
|
|
024 |
175-5912
|
HARNESS, JUMPER, STROBE [LITTERHAWK] (Tennant Industrial) |
1 |
|
|
025 |
175-3202
|
Screw M8-1.25 x 20mm |
4 |
|
|
