| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
175-7551
|
Screw kit 3 1/2 x 16 (pkg of 20) |
2 |
|
|
002 |
999-0632
|
Washer 1/4 split lock stainless steel |
4 |
|
|
003 |
999-0018
|
Bolt 1/4-20 x 1/2 hex cap grade 5 zinc plated |
4 |
|
|
004 |
991-9284
|
50amp charger plug SB50 with pins (red) |
1 |
|
|
005 |
999-1109
|
Screw 6-32 x 3/4 pan head phillips stainless steel |
2 |
|
|
006 |
175-6097
|
Hub cap |
2 |
|
|
007 |
175-7765
|
Teal Battery base housing (OBSOLETE) |
1 |
|
|
008 |
175-6591
|
Strain relief bushing |
1 |
|
|
009 |
175-6600
|
Grommet |
1 |
|
|
010 |
175-6601
|
Wire assembly 14/2 x 45 inches (OBSOLETE) |
1 |
|
|
011 |
175-0339
|
P clamp |
1 |
|
|
012 |
999-0393
|
Washer 3/16 flat aluminum |
1 |
|
|
013 |
999-0447
|
Screw 6-32 x 1/2 pan head phillips zinc plated |
1 |
|
|
014a |
175-7966
|
Vacuum hose with short cuffs |
1 |
|
|
014b |
991-5139
|
Vacuum hose with short cuffs |
1 |
(NON-OEM) |
|
015a |
998-0010
|
Battery jumper cable - ring type (red) |
1 |
|
|
015b |
991-6025
|
Wire 4 x14.5, 3/8 ring x 3/8 ring |
1 |
(NON-OEM) |
|
016 |
999-1165
|
Screw 8-32 x 3/8 truss head phillips stainless steel |
4 |
|
|
017 |
175-2121
|
Battery terminal cover (clear) |
4 |
|
|
018a |
175-3369
|
Hood latch |
2 |
|
|
018b |
991-8561
|
Rubber draw latch with keeper |
2 |
|
|
019 |
175-0888
|
4 inch swivel caster wheel |
2 |
|
|
020 |
999-0553
|
Washer 5/16 medium split lock stainless steel |
8 |
|
|
021 |
175-0030
|
1.5amp circuit breaker |
8 |
|
|
022 |
999-0018
|
Bolt 1/4-20 x 1/2 hex cap grade 5 zinc plated |
4 |
|
|
023 |
999-0632
|
Washer 1/4 split lock stainless steel |
4 |
|
|
024 |
175-6098
|
Axle bracket |
2 |
|
|
025 |
175-6603
|
Axle (OBSOLETE) |
1 |
|
|
026 |
999-0187
|
Washer 1/2 flat plain finish |
2 |
|
|
027 |
999-0559
|
Washer 1/2 x 1/4 flat stainless steel |
2 |
|
|
028 |
175-1902
|
Wheel |
2 |
|
|
029a |
175-1103
|
Battery cable boot (black) |
2 |
|
|
029b |
175-1103
|
Battery cable boot (black) |
2 |
|
|
031 |
175-6604
|
Wire assembly #14 x 17 inch |
1 |
|
|
032a |
175-7966
|
Vacuum hose with short cuffs |
1 |
|
|
032b |
991-5139
|
Vacuum hose with short cuffs |
1 |
(NON-OEM) |
|
033 |
999-0148
|
Washer #6 external star lock zinc plated |
2 |
|
|
034a |
162-0011
|
12V 105Ah wet battery (SNSR) |
2 |
|
|
035 |
999-0493
|
Bolt 3/8-16 x 3/4 hex head stainless steel |
2 |
|
|
036 |
999-0034
|
Washer 3/8 split lock plain finish |
2 |
|
|
037 |
162-5124
|
24V 12amp smart battery charger with small SB50 red plug |
1 |
|
|
034b |
162-0011
|
12V 105Ah wet battery (SNSR) |
2 |
|
|
034b |
162-0045
|
12V 140Ah AGM battery |
2 |
|
|
