| # | Part | Description |
Req | Notes | Availability |
|---|
000a |
175-1627
|
16 inch brush assembly |
1 |
|
|
000b |
175-1628
|
22 inch brush assembly |
1 |
|
|
000c |
175-1629
|
26 inch brush assembly |
1 |
|
|
001a |
175-1630
|
16 inch brush shaft |
1 |
|
|
001b |
175-1631
|
22 inch brush shaft |
1 |
|
|
001c |
175-1632
|
26 inch brush shaft |
1 |
|
|
002 |
175-1633
|
Brush pulley |
1 |
|
|
003a |
175-0069
|
Brush bearing |
2 |
(OEM) |
|
003b |
991-5125
|
Brush bearing |
2 |
(NON-OEM) |
|
004 |
175-1634
|
Brush shaft block with slot |
1 |
|
|
005 |
999-0477
|
Screw 10-24 x 5/16 truss head phillips zinc |
2 |
|
|
006a |
175-1635
|
16 inch cylinder brush assembly |
1 |
|
|
006b |
175-1636
|
22 inch brush assembly |
1 |
|
|
006c |
175-1637
|
26 inch brush |
1 |
|
|
007 |
175-1639
|
Bearing cup |
1 |
|
|
008 |
175-1640
|
Brush shaft block without slot |
1 |
|
|
N/S |
175-1638
|
26 inch sleeve |
1 |
|
|
