Rear Panel

#PartDescription ReqNotesAvailability
001 175-5021 Grommet (OBSOLETE) 1
002 175-5022 36V 1000Ah wet battery (Tennant Industrial) 1
003 999-0507 Bolt M6-1 x 16mm hex head full thread plain finish 8
004 N/A Not available 8 (not available) Washer
005 999-0632 Washer 1/4 split lock stainless steel 8
006 999-0439 Nut M6-1 hex coarse thread 8
007 999-0181 Nut 1/4-20 hex jam plain finish 2
008 175-2022 Squeegee tool 1
009 175-2009 WASHER, SEALING, 0.28B 0.75D SS, NEO 1
010 999-0053 Washer #10 split lock plain finish 1
011 999-0460 Nut 10-32 hex 1
012 175-5025 Squeegee handle (OBSOLETE) 1
013 999-0507 Bolt M6-1 x 16mm hex head full thread plain finish 3
014 N/A Not available 3 (not available) Washer
015 999-0632 Washer 1/4 split lock stainless steel 3
016 999-0439 Nut M6-1 hex coarse thread 3
017 175-6547 Double bend telescopic wand 1
018 999-1007 Washer 3/8 x 1/16 flat nylon 2
020 175-0399 Washer 8mm plain (OBSOLETE) 2
021 175-0382 Washer lock spring (OBSOLETE) 1
022 999-0496 Nut M8-1.25 nylon insert lock stainless steel 1
023 999-0471 Nut M8-1.25 nylon insert lock zinc plated 1
024 175-5028 Pulley cable (OBSOLETE) 1
025 175-5029 Squeegee sheave bracket (OBSOLETE) 1
026 999-1256 Screw 5/16-18 x 3/8 x 1 socket head shoulder 1
027 999-0211 Nut 5/16-18 hex nylon insert lock zinc plated 1
028 175-5031 Cable bracket (OBSOLETE) 1
029 999-0507 Bolt M6-1 x 16mm hex head full thread plain finish 1
030 999-0632 Washer 1/4 split lock stainless steel 1
031 999-1550 Nut M10-1.5 nylon insert lock 1
032 175-5033 Square handle catch plate (OBSOLETE) 1
033 999-0507 Bolt M6-1 x 16mm hex head full thread plain finish 1
035 N/A Not available 2 (not available) Washer
036 999-0632 Washer 1/4 split lock stainless steel 2
037 999-0439 Nut M6-1 hex coarse thread 2
038 175-2049 25amp roller switch (OBSOLETE) 1
039 175-5034 Screw M3 x 30mm 2
040 999-0377 Washer 6 SAE flat plain finish 4
041 999-0051 Washer #6 medium split lock 2
042 175-5035 Nut M3 hex stainless steel (OBSOLETE) 2
043 175-5036 Spacer (OBSOLETE) 1
044 999-1557 Bolt M10-1.5 x 45mm hex head stainless steel 1
045 999-1550 Nut M10-1.5 nylon insert lock 1
046 175-5038 Nylon bushing (OBSOLETE) 1
047 175-5039 Rear shroud (OBSOLETE) 1
048 999-1297 Screw M8 x 50mm hex head stainless steel 2
049 175-0399 Washer 8mm plain (OBSOLETE) 2
050 999-0507 Bolt M6-1 x 16mm hex head full thread plain finish 4
051 N/A Not available 4 (not available) Washer
052 999-0632 Washer 1/4 split lock stainless steel 4
053 999-0439 Nut M6-1 hex coarse thread 4
054 175-5041 Warning label flammable areas (OBSOLETE) 1
055 175-5042 Squeegee handle decal (OBSOLETE) 1
056 175-2701 Plug 2
057 175-5043 Handle grip 1
058 175-3226 Insulated stand off 1
059 999-0644 Bolt 1/4-20 x 1/2 hex head stainless steel 1
061 999-0632 Washer 1/4 split lock stainless steel 2
