| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
175-0449
|
Hood support bracket (OBSOLETE) |
1 |
|
|
002 |
999-1029
|
Screw 10-24 x 5/8 truss head phillips stainless steel |
4 |
|
|
003 |
175-0450
|
Mounting bracket (OBSOLETE) |
4 |
|
|
004 |
175-0451
|
Hood hinge (OBSOLETE) |
1 |
|
|
006 |
999-0998
|
Washer #10 flat stainless steel |
8 |
|
|
007 |
999-0053
|
Washer #10 split lock plain finish |
4 |
|
|
008 |
175-0447
|
Nut M5 hex (OBSOLETE) |
4 |
|
|
009 |
175-0454
|
Plastic hood |
2 |
|
|
010 |
175-2897
|
Screw M5 x 16mm |
10 |
|
|
011 |
999-0998
|
Washer #10 flat stainless steel |
10 |
|
|
012 |
999-0053
|
Washer #10 split lock plain finish |
10 |
|
|
013 |
175-0447
|
Nut M5 hex (OBSOLETE) |
10 |
|
|
014 |
175-0456
|
Battery cable & 50 A connector assembly (OBSOLETE) |
1 |
|
|
015 |
175-0457
|
Screw 6-32 x 1 socket head (OBSOLETE) |
2 |
|
|
016 |
999-0051
|
Washer #6 medium split lock |
2 |
|
|
017 |
999-0195
|
Nut 6-32 hex plain |
2 |
|
|
018 |
175-2049
|
25amp roller switch (OBSOLETE) |
1 |
|
|
020 |
999-1167
|
Bolt 6-32 x 1 hex head stainless steel |
2 |
|
|
021 |
999-0377
|
Washer 6 SAE flat plain finish |
2 |
|
|
022 |
999-0051
|
Washer #6 medium split lock |
2 |
|
|
023 |
999-0195
|
Nut 6-32 hex plain |
2 |
|
|
024 |
991-2105
|
SB50 50amp charger plug with pins (gray) |
1 |
|
|
