T3 ORBITAL Solution Tank Assembly - Lower

#PartDescriptionPriceReqNotesAvailability
1a 275-5962 Front shroud kit FaST (teal) $693.66 1 (standard model) usually ships 1-5 days
1b 275-5965 Front shroud kit ec-H2O (teal) $769.12 1 (ec-H2O model) usually ships 1-5 days
2 275-5963 T3 decal (teal) $11.88 2 (T3) ships same day
3 275-9896 Logo decal (Tennant Industrial) $55.28 2 (ec-H2O) usually ships 5-16 days
4 275-9896 Logo decal (Tennant Industrial) $55.28 1 (ec-H2O) usually ships 5-16 days
5 175-7810 Shroud attachment bracket $17.71 2 ships same day
6 999-1383 Screw M6-1 x 16mm hex head stainless steel $0.99 10 ships same day
7 175-7835 Shroud support bracket $27.72 2 usually ships 1-5 days
8 999-0531 Screw M5-.8 x 16mm pan head slotted zinc $0.99 1 ships same day
9 999-0998 Washer #10 flat stainless steel $0.99 1 ships same day
10 175-7825 Solution fill port cap $3.96 1 ships same day
11 175-2651 Support cable $25.63 1 ships same day
12 999-1084 Screw M6-1 x 16mm truss head slotted stainless steel $0.99 1 ships same day
13 175-0152 Spacer $3.85 1 usually ships 5-16 days
14 175-2678 Hose clamp $3.96 1 usually ships 5-16 days
15 275-5871 Plastic fitting $3.30 1 ships same day
16 175-7828 Solution drain hose $37.62 1 ships same day
17 175-7829 Tank drain cap $45.76 1 ships same day
18 175-7830 Cap plug (gray) $18.70 1 ships same day
19 175-7831 Rubber gasket $9.35 1 usually ships 5-16 days
20 175-7832 Mesh filter screen stainless steel $16.28 1 ships same day
21 175-7833 Solution tank $1,228.15 1 usually ships 5-16 days
22 175-7834 Plastic fitting $8.80 1 ships same day
23 999-0335 Washer 1/4 x 5/8 SAE flat stainless steel $0.99 1 ships same day
24 999-0507 Bolt M6-1 x 16mm hex head full thread plain finish $0.99 1 ships same day
26 999-0531 Screw M5-.8 x 16mm pan head slotted zinc $0.99 2 ships same day
27 175-7808 1/2 inch insulated P clamp $3.85 2 usually ships 1-5 days
