# | Part | Description | Price | Req | Notes | Availability |
3b |
991-8570
|
Bumper wheel |
$2.81
|
2 |
|
ships same day |
0 |
175-7951
|
20 inch (500mm) squeegee assembly |
$381.50
|
1 |
(includes 1-18) |
ships same day |
1 |
999-0496
|
Nut M8-1.25 nylon insert lock stainless steel |
$1.08
|
2 |
|
ships same day |
2 |
999-0024
|
Washer 5/16 flat stainless steel |
$1.34
|
4 |
|
ships same day |
3a |
175-7919
|
Guide wheel |
$4.95
|
2 |
|
ships same day |
4 |
175-2249
|
Sleeve |
$3.08
|
2 |
|
usually ships 6-16 days |
5 |
175-7952
|
Right hand mounting plate |
$41.47
|
1 |
|
usually ships 6-16 days |
6 |
175-3298
|
Bolt M6-1 x 12mm hex head |
$4.06
|
2 |
|
ships same day |
7 |
999-1625
|
Nut M10-1.5 hex jam stainless steel |
$1.54
|
2 |
|
ships same day |
8a |
175-7953
|
Swivel caster wheel |
$21.78
|
2 |
|
ships same day |
8b |
991-8581
|
Swivel caster wheel |
$10.25
|
2 |
|
ships same day |
9 |
175-7954
|
Star knob |
$4.95
|
4 |
|
ships same day |
10 |
175-7955
|
20 inch (500mm) squeegee weldment |
$307.45
|
1 |
|
ships same day |
11 |
999-0785
|
Screw M8-1.25 x 30mm hex head stainless steel |
$2.09
|
2 |
|
ships same day |
12 |
999-1424
|
Nut M8-1.25 hex stainless steel |
$1.65
|
4 |
|
ships same day |
13 |
275-1548
|
20 inch (500mm) squeegee blade retainer |
$44.44
|
1 |
|
ships same day |
14 |
999-1155
|
Screw M8-1.25 x 60mm hex head |
$1.87
|
4 |
|
ships same day |
15 |
175-7957
|
Left hand mounting plate |
$40.37
|
1 |
|
usually ships 6-16 days |
16a |
175-7958
|
Squeegee blade 20 inch linatex front |
$19.25
|
1 |
|
ships same day |
16b |
175-7959
|
Squeegee blade 20 inch gum rubber front |
$18.26
|
1 |
|
ships same day |
16c |
175-7960
|
Squeegee blade 20 inch oil resistant front |
$54.45
|
1 |
|
ships same day |
17a |
175-7961
|
Squeegee blade 20 inch linatex rear (red) |
$22.22
|
1 |
|
usually ships 6-16 days |
17b |
175-7962
|
Squeegee blade 20 inch gum rubber rear (tan) |
$21.01
|
1 |
|
ships same day |
17c |
175-7963
|
Squeegee blade 20 inch oil resistant rear |
$71.83
|
1 |
(OEM) |
ships same day |
17d |
994-0081
|
Squeegee blade 24 inch gum rubber front |
$10.94
|
1 |
(NON-OEM) |
ships same day |
18 |
175-7964
|
20 inch squeegee strap assembly |
$185.46
|
1 |
|
usually ships 6-16 days |
19 |
175-4772
|
Hose bracket |
$3.96
|
1 |
|
ships same day |
20a |
175-7966
|
Vacuum hose with short cuffs |
$53.11
|
1 |
(OEM) |
ships same day |
20b |
991-5139
|
Vacuum hose with short cuffs |
$23.29
|
1 |
(NON-OEM) |
ships same day |
