| # | Part | Description | Price | Req | Notes | Availability |
|---|
1a |
275-9252
|
24V 1HP brush motor assembly |
$1,484.34
|
1 |
(includes 1b-3) |
ships same day |
1b |
275-9253
|
Carbon brush assembly (pkg of 4) |
$112.64
|
1 |
(includes 1c) |
usually ships 1-5 days |
1c |
175-2600
|
Carbon brush |
$34.65
|
4 |
|
ships same day |
1d |
275-9254
|
Motor gearbox |
$848.54
|
1 |
|
usually ships 1-5 days |
1e |
991-2121
|
24V .75HP brush motor assembly with gear box |
$416.75
|
1 |
(NON-OEM) |
ships same day |
1f |
275-5908
|
Brush motor leads |
$4.88
|
2 |
|
usually ships 10-16 days |
2 |
275-9255
|
Connector |
$10.62
|
1 |
|
usually ships 1-5 days |
3 |
275-5910
|
Square keyway |
$5.28
|
1 |
|
ships same day |
4 |
999-0777
|
Screw M4-.7 x 10mm hex head plain finish |
$0.99
|
1 |
|
ships same day |
5 |
999-1083
|
Washer #8 internal star lock stainless steel |
$0.99
|
1 |
|
ships same day |
6 |
175-5797
|
Washer 1/6 flat zinc |
$4.09
|
1 |
|
ships same day |
7 |
175-3671
|
Hose clamp |
$4.88
|
1 |
|
usually ships 10-16 days |
8 |
175-7913
|
Solution tube |
$152.79
|
1 |
|
usually ships 10-16 days |
9a |
275-9902
|
17 inch (430mm) housing kit |
$290.40
|
1 |
(17 inch) |
ships same day |
9b |
275-5916
|
20 inch(500mm) brush housing |
$418.11
|
1 |
(20 inch) |
usually ships 10-16 days |
10 |
175-1238
|
Moving parts decal |
$5.50
|
1 |
|
usually ships 10-16 days |
11 |
175-1437
|
Spacer |
$9.68
|
2 |
|
ships same day |
12 |
999-1225
|
Screw M5-.8 x 12mm pan head phillips zinc |
$0.99
|
2 |
|
ships same day |
13 |
999-0053
|
Washer #10 split lock plain finish |
$0.99
|
2 |
|
ships same day |
14 |
999-0998
|
Washer #10 flat stainless steel |
$0.99
|
2 |
|
ships same day |
15 |
175-7921
|
Brush plate clamp |
$21.23
|
1 |
|
ships same day |
16 |
175-7924
|
Spring clip |
$6.82
|
1 |
|
usually ships 10-16 days |
17 |
275-4800
|
Drive hub |
$234.19
|
1 |
|
usually ships 10-16 days |
18 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
$0.99
|
1 |
|
ships same day |
19 |
999-0553
|
Washer 5/16 medium split lock stainless steel |
$0.99
|
1 |
|
ships same day |
20 |
999-0688
|
Bolt 5/16-18 x 1 1/4 hex head stainless steel |
$0.99
|
1 |
|
ships same day |
21 |
175-7917
|
Water containment ring |
$9.35
|
1 |
|
ships same day |
22 |
999-0562
|
Bolt 3/8-16 x 1 hex head stainless steel |
$1.50
|
4 |
|
ships same day |
23 |
175-4494
|
Washer M10 |
$4.09
|
4 |
|
usually ships 10-16 days |
24 |
999-0355
|
Washer 3/8 x 7/8 SAE flat stainless steel |
$0.99
|
4 |
|
ships same day |
25 |
275-5913
|
Pin |
$26.95
|
1 |
|
usually ships 10-16 days |
26 |
175-4701
|
Pin head |
$19.80
|
1 |
|
usually ships 10-16 days |
27a |
175-7923
|
17 inch (430mm) bumper with bristle skirt |
$93.96
|
1 |
(17 inch) |
ships same day |
27b |
175-7916
|
20 inch (500mm) bumper with bristle skirt |
$144.76
|
1 |
(20 inch) |
ships same day |
28 |
999-0770
|
Screw M8-1.25 x 30mm flat head socket stainless steel |
$2.62
|
1 |
|
ships same day |
29a |
175-7919
|
Guide wheel |
$5.50
|
1 |
|
ships same day |
29b |
991-8570
|
Bumper wheel |
$2.55
|
1 |
|
ships same day |
30 |
175-2249
|
Sleeve |
$3.83
|
1 |
|
ships same day |
31 |
999-0024
|
Washer 5/16 flat stainless steel |
$1.34
|
1 |
|
ships same day |
32 |
999-0496
|
Nut M8-1.25 nylon insert lock stainless steel |
$1.08
|
1 |
|
ships same day |
33 |
175-3718
|
Knob |
$4.88
|
1 |
|
ships same day |
34 |
275-5914
|
Compression spring |
$9.57
|
1 |
|
usually ships 10-16 days |
35 |
275-5915
|
Nut M14 x 2mm hex head stainless steel |
$4.88
|
1 |
|
ships same day |
