| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
175-2842
|
Check valve |
|
|
|
002 |
175-8872
|
24V solenoid valve |
|
|
|
003 |
175-4310
|
Solution filter bowl assembly |
|
|
|
004 |
175-4191
|
24V 100PSI solution pump |
|
|
|
004b |
991-6047
|
24V pump 100PSI |
|
(NON-OEM) |
|
005 |
175-4303
|
Inline filter with mesh screen |
|
|
|
006 |
175-8872
|
24V solenoid valve |
|
|
|
007a |
175-4308
|
24V solenoid valve |
1 |
(if solenoid valve is leaking try replacing the plunger with spring first before replacing entire solenoid valve) |
|
007b |
991-8598
|
Replacement plunger with spring for solenoid valve |
1 |
|
|
008 |
175-8836
|
Brass tip fitting |
|
|
|
009 |
175-6431
|
Quick-jet cap |
|
|
|
010 |
175-4194
|
Quick jet cap (green) |
|
|
|
