C20-608165 Base Assembly

#PartDescriptionPriceReqNotesAvailability
001 175-3963 Gear mounting base (OBSOLETE) $61.60 1 usually ships 1-5 days
002 999-9090 Screw M5-.8 x 25mm hex head stainless steel $1.19 4 ships same day
003 999-9097 Washer M8 flat stainless steel $0.99 3 ships same day
004 999-0496 Nut M8-1.25 nylon insert lock stainless steel $1.08 3 ships same day
005 175-3962 Washer 6 x 16 x 1.5mm plain (OBSOLETE) $1.58 4 usually ships 1-5 days
006 999-0497 Nut M6-1 nylon insert lock stainless steel $0.99 4 ships same day
007 175-7245 Transportation axle (OBSOLETE) $20.02 1 usually ships 1-5 days
008 N/A Not available Call for price 2 5 inch wheel usually ships 3-26 days
009 175-3947 Washer 12.35 plain $3.04 2 usually ships 10-16 days
010 175-3945 External retaining ring 12 $2.90 4 usually ships 10-16 days
011 999-0806 Washer M12 wave zinc plated $1.39 2 ships same day
012 175-3960 Axle clamp block (OBSOLETE) $3.30 2 usually ships 1-5 days
013 175-7247 Screw 5 x 20 pan head self tapping (OBSOLETE) $0.99 8 usually ships 1-5 days
014 175-7246 Front axle (OBSOLETE) $20.02 1 usually ships 1-5 days
015 175-7248 Front axle block clamp (OBSOLETE) $2.64 2 usually ships 1-5 days
016 175-3958 Screw M5 x 16 (OBSOLETE) $0.99 2 usually ships 1-5 days
017 175-3936 Washer 5 plain (OBSOLETE) $1.32 2 usually ships 1-5 days
018 999-0998 Washer #10 flat stainless steel $0.99 12 ships same day
019 175-7250 Washer 10 lock (OBSOLETE) Call for price 8 usually ships 1-5 days
020 175-7251 Screw 3/8 hex (OBSOLETE) Call for price 4 usually ships 1-5 days
021 175-7252 Screw M10 x 65mm hex (OBSOLETE) Call for price 1 usually ships 1-5 days
022 175-7253 Nut M10 (OBSOLETE) Call for price 1 usually ships 1-5 days
023 175-7254 Spacer $642.07 1 usually ships 1-5 days
024 175-7255 Drive pulley (OBSOLETE) Call for price 1 usually ships 1-5 days
025 175-7256 Washer 8 plain (OBSOLETE) Call for price 2 usually ships 1-5 days
026 175-3954 Washer lock 8 (OBSOLETE) $0.99 2 usually ships 1-5 days
027 175-7257 Screw self tapping (OBSOLETE) Call for price 1 usually ships 1-5 days
028 175-7281 Big mouth pad center lock (OBSOLETE) $13.42 1 usually ships 1-5 days
029 175-7258 Screw self tapping (OBSOLETE) Call for price 3 usually ships 1-5 days
030 175-7259 Screw M8 x 20mm hex head $110.66 1 usually ships 1-5 days
031 N/A Not available Call for price 1 (Tank lid) usually ships 3-26 days
032 175-7261 Belt (OBSOLETE) $73.59 1 usually ships 1-5 days
033 175-7262 Drive pulley (OBSOLETE) $146.96 1 usually ships 1-5 days
034 175-7263 Bearing (OBSOLETE) $43.34 2 usually ships 1-5 days
035 175-7264 Spacer (OBSOLETE) $2.51 1 usually ships 1-5 days
036 175-7265 Washer lock (OBSOLETE) $2.24 2 usually ships 1-5 days
037 175-7266 Drive shaft key (OBSOLETE) Call for price 1 usually ships 1-5 days
038 175-7267 Drive shaft (OBSOLETE) $12.21 1 usually ships 1-5 days
039 175-7268 Screw M10 x 32 (OBSOLETE) Call for price 4 usually ships 1-5 days
040 175-7269 Drive shaft mounting plate (OBSOLETE) $38.72 1 usually ships 1-5 days
041 175-7270 Frame bumper (OBSOLETE) Call for price 1 usually ships 1-5 days
042 175-7271 Frame (OBSOLETE) Call for price 1 usually ships 1-5 days
043 175-7273 Nut M10 cap (OBSOLETE) Call for price 4 usually ships 1-5 days
044 175-7272 External retaining ring (OBSOLETE) $1.85 2 usually ships 1-5 days
045 175-7274 Washer 19 wave $3.08 2 usually ships 1-5 days
046 N/A Not available Call for price 2 6 1/4 inch wheel usually ships 3-26 days
047 175-7276 Front axle cap $4.62 2 usually ships 1-5 days
048a 175-7277 Motor (OBSOLETE) $911.90 1 usually ships 1-5 days
048b 175-7278 Carbon brushes (set of 4) $147.18 1 usually ships 1-5 days
048c 175-7279 Rectifier 50A 1000V (OBSOLETE) $58.96 1 usually ships 1-5 days
049 175-7280 Motor key (OBSOLETE) Call for price 1 usually ships 1-5 days
050 999-1368 Screw M8-1.25 x 60mm hex head stainless steel $3.41 3 ships same day
