| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
162-0002
|
12V 185Ah wet battery (SNSR) |
|
|
|
2 |
162-0047
|
12V 215Ah AGM battery (Group J185) (SNSR) |
|
|
|
3 |
175-1204
|
36V 25amp battery charger with small SB50 gray plug |
|
|
|
4 |
162-5062
|
36V 20amp battery charger with small SB50 gray plug |
|
|
|
5 |
991-8566
|
Onboard battery charger power cord |
|
|
|
6 |
175-1198
|
Charger plug and cable assembly (OBSOLETE) |
|
|
|
7 |
175-1233
|
Cloth bag |
|
|
|
8 |
275-0628
|
Paper filter bag (pkg of 10) |
|
|
|
9 |
175-1780
|
3 inch swivel caster wheel |
|
|
|
10 |
175-1072
|
8 inch wheel |
|
|
|
11a |
175-0292
|
4 inch rear wheel (gray) |
|
|
|
11b |
991-1913
|
4 inch wheel (gray) |
|
(NON-OEM) |
|
12 |
275-7527
|
20 inch (500mm) pad driver assembly |
|
|
|
13a |
991-8577
|
Pad retainer |
|
|
|
13b |
991-2201
|
Center-Lok II pad holder - right hand thread (black) |
|
(NON-OEM) |
|
