| # | Part | Description |
Req | Notes | Availability |
|---|
1a |
162-0003
|
6V 225Ah wet battery (SNSR) |
4 |
|
|
1b |
162-0005
|
6V 305Ah wet battery (SNSR) |
4 |
|
|
1c |
162-6021
|
6V 189Ah gel battery (SNSR) |
4 |
|
|
1d |
162-0043
|
6V 224Ah AGM battery (Group GC2) (SNSR) |
4 |
|
|
2a |
275-4959
|
Battery bracket |
1 |
(after SN 10523205) |
|
2b |
275-8190
|
Battery bracket |
1 |
(before SN 10523206) (replaced by 2a) |
|
3 |
275-9408
|
Battery tray |
1 |
|
|
4 |
999-0499
|
Bolt M8-1.25 x 20mm hex head full thread stainless steel |
2 |
|
|
5 |
175-7920
|
Washer M8 flat stainless steel |
4 |
|
|
6 |
175-2130
|
Strap |
1 |
|
|
7a |
998-0010
|
Battery jumper cable - ring type (red) |
3 |
|
|
7b |
991-6025
|
Wire 4 x14.5, 3/8 ring x 3/8 ring |
3 |
(NON-OEM) |
|
8 |
175-1103
|
Battery cable boot (black) |
8 |
|
|
9a |
175-1352
|
Battery insert |
2 |
(after SN 10523205) |
|
9b |
375-2512
|
Foam battery spacer |
2 |
(before SN 10523206) |
|
10 |
999-0211
|
Nut 5/16-18 hex nylon insert lock zinc plated |
8 |
|
|
11 |
275-8192
|
Battery support angle |
1 |
|
|
12 |
275-0732
|
Wire assembly (red) |
1 |
|
|
13a |
275-0733
|
Wire assembly (red) |
1 |
(includes 13b-13c) |
|
13b |
275-9406
|
Anderson connector |
1 |
|
|
13c |
275-9407
|
Anderson contact terminal |
1 |
|
|
14 |
175-9591
|
Battery cable (black) |
1 |
|
|
15 |
275-8193
|
1 foot nylon sleeve |
1 |
|
|
16 |
175-2202
|
Nylon wire tie |
3 |
|
|
17 |
999-0784
|
Screw M8-1.25 x 16mm hex head stainless steel |
2 |
|
|
18 |
275-5948
|
Battery terminal cover (black) |
8 |
|
|
N/S |
275-8191
|
Battery spacer angle |
2 |
(before SN 10523206) (replaced by 2a) |
|
N/S |
999-0688
|
Bolt 5/16-18 x 1 1/4 hex head stainless steel |
8 |
(maintenance free) |
|
N/S |
999-0593
|
Nut 5/16-18 hex stainless steel |
8 |
(maintenance free) |
|
