# | Part | Description | Price | Req | Notes | Availability |
000a |
175-1052
|
26.5 inch squeegee assembly (OBSOLETE) |
$190.00
|
1 |
(1701) (includes 1-3, 5-6, 14-18a, 19a, 20a, 21a, 22a, and 23-25a) |
usually ships 6-16 days |
000b |
175-0886
|
27 inch squeegee assembly |
$479.70
|
1 |
(2001) (includes 1-3, 5-6, 14-17, 18b, 19b, 20b, 21b, 22b, 23-24, and 25b) |
usually ships 6-16 days |
000c |
175-1054
|
Squeegee assembly curved 31 inch (780mm) (OBSOLETE) |
$377.30
|
1 |
(2400) (includes 1-3, 5-6, 14-17, 18c, 19c, 20c, 21c, 22c, 23-24, and 25c) |
usually ships 6-16 days |
001 |
175-0117
|
Guide wheel with bushing |
$9.68
|
2 |
|
ships same day |
002 |
999-1039
|
Screw 5/16-18 x 1 1/2 truss head phillips stainless steel |
$1.50
|
2 |
|
ships same day |
003 |
175-2812
|
Knob |
$9.35
|
2 |
|
ships same day |
004 |
175-3073
|
Squeegee mount bracket |
$328.30
|
1 |
|
usually ships 6-16 days |
005 |
175-1055
|
Gasket |
$13.42
|
1 |
|
ships same day |
006 |
999-0152
|
Nut 1/4-20 nylon insert lock zinc plated |
$0.99
|
2 |
|
ships same day |
007 |
175-3068
|
Squeegee lift cable |
$29.80
|
1 |
|
ships same day |
008 |
999-0561
|
Bolt 1/2-13 x 1 hex head stainless steel |
$2.98
|
2 |
|
ships same day |
009 |
999-0126
|
Washer 1/2 split lock |
$1.28
|
2 |
|
ships same day |
010 |
999-0559
|
Washer 1/2 x 1/4 flat stainless steel |
$0.99
|
4 |
|
ships same day |
011 |
175-2743
|
Sleeved bushing |
$3.50
|
2 |
|
ships same day |
012a |
175-1016
|
Pivot mount bracket |
$105.05
|
1 |
(1701 and 2001E) |
ships same day |
012b |
175-1056
|
Squeegee pivot mount with drive |
$155.00
|
1 |
(2400 and 2001B) |
usually ships 1-5 days |
013 |
175-2970
|
Extension spring |
$6.00
|
2 |
|
usually ships 6-16 days |
014 |
999-0030
|
Bolt 5/16-18 x 5/8 hex head grade 5 zinc plated |
$1.04
|
2 |
|
ships same day |
015 |
999-0553
|
Washer 5/16 medium split lock stainless steel |
$0.99
|
2 |
|
ships same day |
016 |
175-3091
|
Squeegee roller assembly |
$36.96
|
2 |
|
ships same day |
017 |
999-0586
|
Screw 10-24 x 1/2 truss head stainless steel |
$0.90
|
12 |
|
ships same day |
018a |
175-1058
|
17 inch front Squeegee plate (OBSOLETE) |
$21.00
|
1 |
(1701) |
usually ships 1-5 days |
018b |
175-1059
|
27 inch (680mm) front squeegee plate |
$27.72
|
1 |
(2001) |
usually ships 6-16 days |
018c |
N/A
|
Not available |
Call for price
|
1 |
(2400 - front squeegee plate) |
usually ships 30-32 days |
019a |
175-1060
|
Squeegee backing blade |
$67.30
|
2 |
(1701) |
usually ships 1-5 days |
019b |
175-2036
|
Squeegee blade 27 inch (680mm) urethane |
$37.73
|
2 |
(2001) |
ships same day |
019c |
N/A
|
Not available |
Call for price
|
2 |
(2400 - serrated squeegee blade) |
usually ships 30-32 days |
020a |
N/A
|
Not available |
Call for price
|
2 |
(1701 - squeegee blade spacer) |
usually ships 30-32 days |
020b |
175-1063
|
Squeegee blade spacer (OBSOLETE) |
$21.40
|
2 |
(2001) |
usually ships 6-16 days |
020c |
275-4626
|
Squeegee spacer (OBSOLETE) |
$13.10
|
2 |
(2400) |
usually ships 1-5 days |
021a |
175-1060
|
Squeegee backing blade |
$67.30
|
2 |
(1701) |
usually ships 1-5 days |
021b |
175-2036
|
Squeegee blade 27 inch (680mm) urethane |
$37.73
|
2 |
(2001) |
ships same day |
021c |
175-3090
|
31 inch curved squeegee blade urethane |
$63.14
|
2 |
(2400) |
ships same day |
022a |
175-1071
|
Squeegee channel (OBSOLETE) |
$109.80
|
1 |
(1701) |
usually ships 1-5 days |
022b |
175-1067
|
27 inch squeegee weldment |
$127.00
|
1 |
(2001) |
usually ships 6-16 days |
022c |
275-9963
|
Squeegee channel (OBSOLETE) |
$87.54
|
1 |
(2400) |
usually ships 1-5 days |
023 |
999-0393
|
Washer 3/16 flat aluminum |
$0.99
|
2 |
|
ships same day |
024 |
999-0688
|
Bolt 5/16-18 x 1 1/4 hex head stainless steel |
$0.99
|
2 |
|
ships same day |
025a |
175-1068
|
17 inch squeegee plate rear (OBSOLETE) |
$13.30
|
1 |
(1701) |
usually ships 1-5 days |
025b |
175-1069
|
27 inch rear squeegee plate |
$34.21
|
1 |
(2001) |
ships same day |
025c |
175-1070
|
40 inch squeegee weldment |
$260.30
|
1 |
(2400) |
usually ships 1-5 days |
