| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
175-0862
|
TIE, CABLE, NYL, 28.3L .50W 8.0 MAX D (Tennant Industrial) |
4 |
|
|
2 |
175-0863
|
CABLE, 04GA 32.0L BLK .34RING /.34RING (Tennant Industrial) |
1 |
(before SN 001706) |
|
3 |
175-0864
|
CABLE, 02GA 27.0L BLK .34RING /.34RING (Tennant Industrial) |
2 |
|
|
4 |
175-0865
|
CABLE, 04GA 09.0L BLK .28RING /.34RING (Tennant Industrial) |
4 |
(before SN 001706) |
|
5 |
175-0866
|
CABLE, 06GA 11.0L BLK .28RING /.34RING (Tennant Industrial) |
1 |
(before SN 001706) |
|
6 |
999-0406
|
Washer 5/16 internal star lock zinc plated |
4 |
|
|
7 |
175-0867
|
WASHER, FLAT, 1.50B 3.50D .18, PL (Tennant Industrial) |
4 |
|
|
8 |
175-0849
|
Nut 5/16-24 hex |
4 |
|
|
9 |
175-0848
|
BUSBAR, .06 0.6W 2.5L 2/.28H (Tennant Industrial) |
2 |
(before SN 001706) |
|
10 |
999-1026
|
Washer #10 internal lock stainless steel |
4 |
|
|
11 |
999-0006
|
Washer 3/16 flat zinc plated |
4 |
|
|
12 |
999-0460
|
Nut 10-32 hex |
4 |
|
|
13 |
999-0499
|
Bolt M8-1.25 x 20mm hex head full thread stainless steel |
4 |
|
|
14 |
999-0471
|
Nut M8-1.25 nylon insert lock zinc plated |
4 |
|
|
15 |
175-0869
|
HARNESS, BATTERY, CONNECTING (Tennant Industrial) |
1 |
|
|
16 |
175-0870
|
SLEEVE, NYL, 1.06ID 14.0L (Tennant Industrial) |
1 |
|
|
17 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
2 |
|
|
18 |
175-0758
|
Bolt M6-1 x 40mm hex head stainless steel |
2 |
|
|
19 |
999-0238
|
Washer 1/4 internal star lock zinc plated |
2 |
(before SN 001706) |
|
20 |
999-0579
|
Nut M8-1.25 hex coarse thread zinc |
4 |
|
|
21 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
4 |
|
|
22 |
999-0201
|
Washer 3/8 internal star lock |
2 |
|
|
23 |
999-0439
|
Nut M6-1 hex coarse thread |
2 |
(before SN 001706) |
|
24 |
999-0016
|
Washer 1/4 flat plain finish |
4 |
(before SN 001706) |
|
N/S |
275-8541
|
CABLE, 02GA 10.0L BLK .34RING /.34RING (Tennant Industrial) |
4 |
(after SN 001705) |
|
N/S |
175-2120
|
6 gauge black wire jumper cable |
1 |
(after SN 001705) |
|
