| # | Part | Description | Price | Req | Notes | Availability |
|---|
1a |
175-0545
|
COVER, TANK, TOP (Tennant Industrial) |
$518.54
|
1 |
(before SN 005000) |
usually ships 1-5 days |
1b |
275-9269
|
Top tank cover (teal) (Tennant Industrial) |
$350.70
|
1 |
(after SN 004999) |
usually ships 1-5 days |
2a |
175-0546
|
COVER, REAR (Tennant Industrial) |
$923.18
|
1 |
(before SN 005000) |
usually ships 1-5 days |
2b |
275-9270
|
Rear cover (teal) (Tennant Industrial) |
$506.34
|
1 |
(after SN 004999) |
usually ships 1-5 days |
3a |
175-0547
|
PLATE, HINGE (Tennant Industrial) |
$211.59
|
2 |
(before SN 005000) |
usually ships 1-5 days |
3b |
275-9271
|
Hinge plate (iron gray) (Tennant Industrial) |
$26.89
|
2 |
(after SN 004999) |
usually ships 1-5 days |
4a |
175-0548
|
HINGE WLDT, W/ PIN (Tennant Industrial) |
$157.98
|
2 |
(before SN 005000) |
usually ships 1-5 days |
4b |
275-9272
|
Hinge weldment with pin (iron gray) (Tennant Industrial) |
$50.27
|
2 |
(after SN 004999) |
usually ships 1-5 days |
5a |
175-0549
|
HINGE ASSY (Tennant Industrial) |
$117.90
|
2 |
(before SN 005000) |
usually ships 1-5 days |
5b |
275-9273
|
Hinge assembly (iron gray) (Tennant Industrial) |
$72.48
|
2 |
(after SN 004999) |
usually ships 1-5 days |
6 |
999-0355
|
Washer 3/8 x 7/8 SAE flat stainless steel |
$0.99
|
24 |
|
ships same day |
7 |
999-0499
|
Bolt M8-1.25 x 20mm hex head full thread stainless steel |
$1.85
|
23 |
|
ships same day |
8a |
375-7802
|
Latch |
$36.50
|
1 |
(OEM) |
usually ships 5-16 days |
8b |
991-8561
|
Rubber draw latch with keeper |
$22.10
|
1 |
(NON-OEM) |
ships same day |
9 |
999-0954
|
Nut M4-.7 nylon insert lock stainless steel |
$0.99
|
4 |
|
ships same day |
10 |
999-0534
|
Screw M4-.7 x 10mm pan head slotted zinc |
$0.99
|
4 |
|
ships same day |
11 |
175-0550
|
Sleeve |
$3.40
|
1 |
|
ships same day |
12 |
175-0551
|
ROD (Tennant Industrial) |
$119.74
|
1 |
|
usually ships 1-5 days |
13a |
175-0552
|
PLATE (Tennant Industrial) |
$40.58
|
1 |
(before SN 005000) |
usually ships 1-5 days |
13b |
275-9274
|
Plate (iron gray) (Tennant Industrial) |
$40.75
|
1 |
(after SN 004999) |
usually ships 1-5 days |
14 |
999-0501
|
Bolt M8-1.25 x 25mm hex head full thread stainless steel |
$2.64
|
3 |
|
ships same day |
15a |
175-0553
|
COVER WLDT (Tennant Industrial) |
$301.44
|
1 |
(before SN 005000) |
usually ships 1-5 days |
15b |
275-9275
|
Cover weldment (iron gray) (Tennant Industrial) |
$164.16
|
1 |
(after SN 004999) |
usually ships 5-16 days |
16 |
175-0554
|
PANEL, FRONT, W/ LABEL (Tennant Industrial) |
$698.90
|
1 |
|
usually ships 1-5 days |
17 |
175-0555
|
ROD, DOOR, REAR (Tennant Industrial) |
$116.23
|
1 |
|
usually ships 1-5 days |
18 |
175-0556
|
SPRING, CMPR, 0.36OD .04WIR 02.5L (Tennant Industrial) |
$32.73
|
1 |
|
usually ships 1-5 days |
19 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.99
|
2 |
|
ships same day |
20 |
175-2361
|
Cotter pin |
$2.20
|
1 |
|
ships same day |
21 |
275-7952
|
Iron bracket (Tennant Industrial) |
$44.92
|
1 |
|
usually ships 5-16 days |
22 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.99
|
2 |
|
ships same day |
23 |
175-0558
|
CAP, VYL, .23ID .750L, BLK (Tennant Industrial) |
$6.01
|
1 |
|
usually ships 1-5 days |
24 |
175-0559
|
P clamp |
$2.20
|
2 |
|
usually ships 5-16 days |
