PowerBoss Nautilus Hose Clamp Assembly-1

#PartDescriptionPriceReqNotesAvailability
1 999-0501 Bolt M8-1.25 x 25mm hex head full thread stainless steel $2.64 4 ships same day
2 999-0501 Bolt M8-1.25 x 25mm hex head full thread stainless steel $2.64 5 ships same day
3 999-0496 Nut M8-1.25 nylon insert lock stainless steel $1.34 1 ships same day
4 999-9097 Washer M8 flat stainless steel $0.99 1 ships same day
5 999-1261 Washer M6 flat stainless steel $0.99 1 ships same day
6 374-4422 Hose retainer Call for price 2 usually ships 1-5 days
7 374-4423 Hose clamp Call for price 1 usually ships 1-5 days
8 374-4322 Clamp $2.53 1 usually ships 1-5 days
9 374-0939 Washer 5/16 conical spring $1.08 7 usually ships 12-16 days
10 374-0940 WASHER-CONICAL SPRING 3/8 Call for price 2 usually ships 1-5 days
11 999-0470 Bolt M8-1.25 x 45mm hex head part thread zinc $0.99 2 ships same day
13 999-9131 Nut M6 x 1 nylon lock stainless steel $0.99 1 ships same day
14 999-0665 Nut M8-1.25 flange lock $0.99 5 ships same day
15 374-4424 Edging Call for price 1 usually ships 1-5 days
16 374-4425 Clamp Call for price 1 usually ships 1-5 days
17 999-9092 Screw M8-1.25 x 20mm hex head stainless steel $2.79 1 ships same day
18 374-4426 Hose tray bracket Call for price 1 usually ships 1-5 days
19 374-4427 Hose clamp Call for price 2 usually ships 1-5 days
20 374-4428 Rear hose tray Call for price 1 usually ships 1-5 days
21 374-4429 Hose clamp bracket assembly Call for price 1 usually ships 1-5 days
22 374-4430 Sleeve Call for price 1 usually ships 1-5 days
23 374-4431 Sleeve Call for price 1 usually ships 1-5 days
24 374-4432 Edging Call for price 2 usually ships 1-5 days
25 374-4433 Center hose bracket Call for price 1 usually ships 1-5 days
26 374-4434 Sleeve Call for price 4 usually ships 1-5 days
27 N/A Not available Call for price (frame) (for reference only) usually ships 3-26 days
28 N/A Not available Call for price (tank mount bracket) (for reference only) usually ships 3-26 days
29 N/A Not available Call for price (filter mount bracket) (for reference only) usually ships 3-26 days
30 N/A Not available Call for price (console) (for reference only) usually ships 3-26 days
N/S 999-0502 Bolt M6-1 x 20mm hex head full thread zinc $0.99 1 ships same day
