Guide Assembly-Cylindrical Models

#PartDescriptionPriceReqNotesAvailability
1 374-3624 Slide bar $111.13 1 usually ships 1-5 days
2 374-3625 Side gasket $27.78 1 usually ships 1-5 days
3 374-3626 Side wall $55.57 1 usually ships 1-5 days
4 174-8941 Lens flange screw $2.48 4 usually ships 1-5 days
5 999-0497 Nut M6-1 nylon insert lock stainless steel $1.03 4 ships same day
6 174-8912 Screw $0.95 6 usually ships 1-5 days
7 374-3627 Angle plate $9.26 1 usually ships 1-5 days
8 374-3628 Guide profile $137.08 1 usually ships 1-5 days
