| # | Part | Description | Price | Req | Notes | Availability |
|---|
M1 |
274-9001
|
VAC MOTOR ASSY, SCV2426 CE |
$469.92
|
1 |
|
usually ships 12-16 days |
M2 |
274-9001
|
VAC MOTOR ASSY, SCV2426 CE |
$469.92
|
1 |
|
usually ships 12-16 days |
M4 |
274-9365
|
MOTOR-3/4HP 36V 1800RPM 40 inchLEADS |
$687.13
|
1 |
|
usually ships 1-5 days |
M6 |
374-3325
|
Brush deck actuator |
$772.73
|
1 |
|
usually ships 1-5 days |
M7 |
274-8535
|
PUMP ASSEMBLY, FLOJET, X RIDE 28 |
$319.64
|
1 |
|
usually ships 1-5 days |
M8 |
374-0216
|
ELECTRIC CHASSIS DRV-ERIDE 250mm(~10.0 inch) |
$3,004.74
|
1 |
|
usually ships 12-16 days |
A1 |
274-9729
|
CONTROLLER, TRIO+ XRIDE DRY (AGM) BAT |
$1,350.70
|
1 |
|
usually ships 1-5 days |
V1 |
274-0850
|
VARISTOR ASY, RING TERMINALS 1/4 inch |
$6.83
|
1 |
|
usually ships 1-5 days |
S2 |
174-8914
|
Key switch |
$27.66
|
1 |
|
usually ships 12-16 days |
S3 |
174-8777
|
Horn switch |
$39.18
|
1 |
|
usually ships 1-5 days |
S4 |
174-6336
|
Mode selector switch assembly |
$131.61
|
1 |
|
usually ships 12-16 days |
S5 |
N/A
|
Not available |
Call for price
|
1 |
(speed potentiometer switch) (part of |
usually ships 3-26 days |
S6 |
274-3344
|
SWITCH, TOGGLE 2POS DPDT ON/ON .687 inchBAT |
$30.11
|
1 |
|
usually ships 12-16 days |
S7 |
274-3822
|
SWITCH, DPST ON/OFF (B100R/ERIDE-WAND) |
$14.08
|
1 |
|
usually ships 1-5 days |
S8 |
274-5768
|
SEAT SWITCH ASY, SCV2426 W/PACKARD |
$98.53
|
1 |
|
usually ships 1-5 days |
S9 |
174-6283
|
3 postion dpst packard switch |
$80.35
|
1 |
|
usually ships 1-5 days |
B1 |
174-8760
|
Float switch |
$119.37
|
1 |
|
usually ships 1-5 days |
CB1 |
174-6302
|
100amp circuit breaker |
$111.95
|
1 |
|
ships same day |
CB2 |
174-6534
|
Circuit breaker 3amp |
$19.77
|
1 |
|
usually ships 12-16 days |
CB3 |
174-5740
|
Circuit Breaker 18 amp |
$41.54
|
1 |
|
usually ships 1-5 days |
CB4 |
174-5740
|
Circuit Breaker 18 amp |
$41.54
|
1 |
|
usually ships 1-5 days |
CB5 |
174-5059
|
Circuit breaker 20 amp (push button) |
$5.70
|
1 |
|
ships same day |
CB6 |
174-5059
|
Circuit breaker 20 amp (push button) |
$5.70
|
1 |
|
ships same day |
H1 |
174-8682
|
Back up alarm |
$63.23
|
1 |
|
ships same day |
Y1 |
274-6857
|
SOLENOID ASY, W/ FEMALE PACKARD 2P |
$107.98
|
1 |
|
usually ships 1-5 days |
Y2 |
374-3269
|
Solenoid assembly with male packard |
$102.43
|
1 |
|
usually ships 1-5 days |
HM1 |
274-5887
|
HOUR METER, 10-80VDC (SCV2426) |
$60.64
|
1 |
|
usually ships 1-5 days |
BDI |
274-6252
|
Battery gauge |
$78.15
|
1 |
|
usually ships 12-16 days |
G1 |
162-0123
|
12V 215Ah AGM battery - DISCOVER ONLY |
$1,026.38
|
3 |
|
ships same day |
R1 |
274-8166
|
POTENTIOMETER BOX ASY, SCV W/PACKARD |
$246.41
|
1 |
|
usually ships 12-16 days |
L1 |
174-6300
|
LED red assembly |
$16.42
|
1 |
|
usually ships 1-5 days |
L2 |
274-2530
|
LED ASSY, AMBER 36VDC W/FEMALE QC |
$14.75
|
1 |
|
usually ships 1-5 days |
N5 |
374-3328
|
Ferrite bead clamp on |
$3.91
|
2 |
|
usually ships 1-5 days |
N6 |
174-5096
|
Torroid |
$3.62
|
1 |
|
usually ships 1-5 days |
C1 |
274-0720
|
CAP 1000PF RING TERM |
$7.08
|
2 |
|
usually ships 1-5 days |
P2 |
374-3329
|
Wire harness |
$68.62
|
1 |
|
usually ships 1-5 days |
P3 |
374-3330
|
Wire harness |
$237.01
|
1 |
|
usually ships 1-5 days |
N/S |
374-3331
|
Main wire harness |
$451.95
|
1 |
|
usually ships 1-5 days |
