# | Part | Description | Price | Req | Notes | Availability |
1a |
174-9066
|
Base frame assembly |
$273.83
|
1 |
(battery model) |
usually ships 1-5 days |
1b |
174-9065
|
Base frame assembly |
Call for price
|
1 |
(electric model) |
usually ships 1-5 days |
2 |
374-1925
|
SEAL - WHEEL |
$1.62
|
4 |
|
usually ships 1-5 days |
3 |
274-7268
|
WHEEL ASSY FOR 14 inch |
$113.08
|
2 |
|
usually ships 1-5 days |
4 |
374-1924
|
BUSH-WHEEL |
$1.70
|
4 |
|
usually ships 1-5 days |
5 |
374-2783
|
WASHER-MAIN WHEEL |
$3.50
|
2 |
|
usually ships 1-5 days |
6 |
999-0773
|
Screw M6-1 x 16mm flat socket head stainless steel |
$0.99
|
2 |
|
ships same day |
7 |
274-0994
|
COVER-WHEEL |
$5.69
|
2 |
|
usually ships 4-14 days |
8 |
274-2699
|
PIN-HEX SOC HEAD |
$13.75
|
1 |
|
usually ships 4-14 days |
9 |
374-1670
|
BUSH LH&RH- PILLAR HANDLE |
$0.97
|
2 |
|
usually ships 4-14 days |
10 |
274-4448
|
KNOB-HANDLE |
$30.47
|
1 |
|
usually ships 4-14 days |
11a |
274-3356
|
COVER W/SEAL |
$24.37
|
1 |
(battery model) |
usually ships 1-5 days |
11b |
274-3665
|
COVER-PILLAR |
$11.95
|
1 |
(electric model) |
usually ships 1-5 days |
12 |
999-1601
|
Screw M5 x 10 flat head stainless steel |
$0.99
|
2 |
|
ships same day |
13 |
174-9068
|
Lifting handle |
$0.97
|
1 |
|
usually ships 1-5 days |
14 |
174-9069
|
Washer |
$2.53
|
2 |
(battery model) |
usually ships 4-14 days |
15 |
174-9070
|
Washer |
$0.90
|
2 |
(battery model) |
usually ships 1-5 days |
16 |
999-0784
|
Screw M8-1.25 x 16mm hex head stainless steel |
$1.74
|
2 |
(battery model) |
ships same day |
17 |
174-9067
|
Battery holder assembly |
$37.87
|
1 |
(battery model) |
usually ships 1-5 days |
