| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
174-3539
|
Rear left tension band |
$24.12
|
1 |
|
usually ships 12-16 days |
2 |
174-8179
|
Squeegee blade rear polyurethane |
$38.76
|
1 |
|
ships same day |
3 |
274-8872
|
38 inch squeegee base assembly |
$378.82
|
1 |
|
usually ships 12-16 days |
4 |
174-8180
|
Squeegee blade front polyurethane |
$47.68
|
1 |
|
ships same day |
5 |
174-7103
|
Front left tension band |
$14.90
|
1 |
|
usually ships 12-16 days |
6 |
174-8938
|
Bushing |
$2.82
|
2 |
|
usually ships 1-5 days |
7 |
174-8338
|
Bolt M5 x 40mm eye stainless steel |
$17.42
|
1 |
|
usually ships 12-16 days |
8 |
999-0495
|
Nut M5-.8 nylon insert lock zinc plated |
$0.99
|
2 |
|
ships same day |
9 |
174-8327
|
Lever |
$12.83
|
1 |
|
usually ships 12-16 days |
10 |
174-8947
|
Screw M5-.8 x 30 hex head stainless steel |
$1.13
|
2 |
|
usually ships 1-5 days |
11 |
999-0740
|
Nut M5-.8 hex stainless steel |
$0.99
|
1 |
|
ships same day |
12 |
174-8341
|
Pressure pin |
$9.48
|
1 |
|
usually ships 12-16 days |
13 |
174-7104
|
Front right tension band |
$12.86
|
1 |
|
usually ships 12-16 days |
14 |
174-3541
|
Rear right tension band |
$31.74
|
1 |
|
usually ships 12-16 days |
15 |
174-7105
|
Latch assembly |
$153.80
|
1 |
(includes 6-12) |
usually ships 12-16 days |
16 |
174-8948
|
Latch |
$41.91
|
1 |
|
usually ships 12-16 days |
