| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
174-3653
|
Nylon spacer |
$0.86
|
1 |
|
ships same day |
2 |
174-3655
|
Squeegee cable |
$49.61
|
1 |
|
ships same day |
3 |
174-3637
|
Caster |
$14.08
|
1 |
|
ships same day |
3 |
174-3657
|
Slider weldment |
$58.14
|
1 |
|
usually ships 4-14 days |
4 |
174-3622
|
Nylon flat washer 1/2 x 3/4 x 5/8 |
$0.86
|
4 |
|
ships same day |
5 |
174-4533
|
20 inch squeegee pivot link |
$24.17
|
1 |
(included in 6a) |
ships same day |
6a |
174-4531
|
20 inch squeegee weldment upgrade kit (See SN note) |
$451.06
|
1 |
(Before SN 20030125 parts are no longer available. Replaced by 174-4531 includes 5, 6b , and 174-7230. After SN 20030024 come with 174-4531 standard) |
usually ships 4-14 days |
6b |
174-4534
|
20 inch squeegee mount weldment |
$155.58
|
1 |
(Recovery hose tube is now on the squeegee mount. Included in 6a) (SN after 20030124 use 174-4534 no kit is needed or model has already been updated to new standard parts) |
ships same day |
7 |
174-3659
|
Nut 1/4-20 jam nyloc stainless steel |
$0.82
|
1 |
|
ships same day |
8 |
999-0609
|
Nut 1/4-20 hex stainless steel |
$0.99
|
1 |
|
ships same day |
9 |
174-8251
|
Washer flat stainless steel |
$0.86
|
3 |
|
ships same day |
10 |
174-3660
|
Spacer 13/32 x 1/2 x 21/64 inch |
$1.38
|
4 |
|
ships same day |
11 |
174-3661
|
Hex head screw #M10-1.50 x 25 stainless steel |
$3.25
|
4 |
|
ships same day |
12 |
174-0190
|
Clevis pin |
$0.98
|
6 |
|
ships same day |
12 |
174-3203
|
Washer 13/32 x 1/32 flat stainless steel |
$0.86
|
1 |
|
ships same day |
13 |
174-3632
|
Plastic groove pulley 2 x 1/4 inches |
$8.03
|
2 |
|
ships same day |
14 |
174-1852
|
Clevis pin 3/8 x 1 1/8 zinc plated |
$1.16
|
1 |
|
ships same day |
15 |
174-1578
|
3/8 rue ring cotter pin |
$1.45
|
7 |
|
ships same day |
16 |
999-1120
|
Nut M10-1.5 nylon insert lock stainless steel |
$3.92
|
4 |
|
ships same day |
17 |
999-0496
|
Nut M8-1.25 nylon insert lock stainless steel |
$1.08
|
1 |
|
ships same day |
