| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
174-8262
|
Stop pedal bracket |
1 |
|
|
2 |
174-8263
|
Clip |
1 |
|
|
3 |
999-1059
|
Screw 4-40 x 3/4 pan head phillips zinc plated |
2 |
|
|
4 |
174-2271
|
Screw 8-32 x 1/2 |
2 |
|
|
5 |
999-0408
|
Nut 4-40 plain machine screw |
2 |
|
|
6 |
999-0479
|
Washer #4 internal star lock zinc plated |
2 |
|
|
7 |
174-7165
|
Remove splash guard decal |
1 |
|
|
8 |
174-8264
|
Switch assembly (with pack conduit) |
1 |
|
|
