| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
174-1766
|
8 Horse power kawasaki FE250 |
1 |
|
|
002 |
999-0109
|
Bolt 5/16-18 x 1 1/2 hex head grade 5 zinc plated |
4 |
|
|
003 |
999-0024
|
Washer 5/16 flat stainless steel |
9 |
|
|
004 |
999-0525
|
Nut 5/16-18 flange lock serrated zinc plated |
4 |
|
|
005 |
174-1079
|
Bolt 3/8-16 x 2 1/4 hex head grade 5 |
4 |
|
|
006 |
999-0034
|
Washer 3/8 split lock plain finish |
4 |
|
|
007 |
174-1091
|
Spacer |
4 |
|
|
008 |
174-0537
|
Washer 3/8 helical stainless steel |
1 |
|
|
009 |
174-1767
|
1 1/4 arbor key spacer |
1 |
|
|
010 |
174-1349
|
Spacer |
1 |
|
|
011 |
174-1082
|
Square keyway |
1 |
|
|
012 |
N/A
|
Not available |
1 |
|
|
013 |
174-1768
|
Regulator break |
1 |
|
|
014 |
991-6001
|
Fuel regulator (T60) |
1 |
|
|
015 |
174-5343
|
Area washer |
1 |
|
|
016 |
174-0344
|
Vacuum pipe weldment |
2 |
|
|
017 |
999-0016
|
Washer 1/4 flat plain finish |
2 |
|
|
018 |
999-0060
|
Washer 1/4 split lock plain finish |
2 |
|
|
019 |
174-5003
|
High pressure hose |
1 |
|
|
020 |
174-0221
|
1/4 brass fitting |
1 |
|
|
021 |
174-5399
|
Female safety connector |
1 |
|
|
022 |
174-5401
|
90 degree male el flared |
1 |
|
|
023 |
174-1769
|
Finger guard |
2 |
|
|
024 |
174-1770
|
Regulator vacuum cover |
1 |
|
|
025 |
174-1771
|
8 Horse power decal emmissions |
1 |
|
|
026 |
174-1379
|
Hose barb 1/8 x 1/8 NPT |
1 |
|
|
027 |
174-1772
|
13 Inch 5/32 hose vacuum |
1 |
|
|
028 |
174-1773
|
13 Inch 3/8 hose |
1 |
|
|
029 |
174-1774
|
Engine pulley |
1 |
|
|
030 |
174-1775
|
90 Degree 3/8 inch brass fitting |
1 |
|
|
