| # | Part | Description |
Req | Notes | Availability |
|---|
000 |
174-5637
|
Pump service kit |
|
|
|
001 |
N/A
|
Not available |
1 |
|
|
002 |
174-5629
|
Brush endbell and rectifier assembly |
1 |
|
|
003 |
N/A
|
Not available |
1 |
|
|
004 |
N/A
|
Not available |
1 |
|
|
005 |
N/A
|
Not available |
1 |
|
|
006 |
N/A
|
Not available |
1 |
|
|
007 |
174-5630
|
Cam and bearing screws |
2 |
|
|
008 |
174-5631
|
Cam and bearing set screw |
1 |
|
|
009 |
174-5632
|
Cam and bearing kit |
1 |
|
|
010 |
N/A
|
Not available |
1 |
|
|
011 |
174-5633
|
Pistons |
2 |
|
|
012 |
174-5634
|
Diaphragm kit (OBSOLETE) |
1 |
|
|
013 |
174-5635
|
Check vavle |
1 |
|
|
014 |
174-5636
|
Upper housing and switch assembly |
1 |
|
|
015 |
N/A
|
Not available |
1 |
|
|
