| # | Part | Description |
Req | Notes | Availability |
|---|
0 |
174-4222
|
Suction cup lock |
1 |
(includes 1-8) |
|
1 |
174-9618
|
Retaining washer |
2 |
|
|
2 |
174-4172
|
Bearing bush |
1 |
|
|
3 |
274-5171
|
FOLDING PLATE |
1 |
|
|
4 |
174-4173
|
Compression spring |
1 |
|
|
5 |
174-4174
|
Pin |
1 |
|
|
6 |
999-9092
|
Screw M8-1.25 x 20mm hex head stainless steel |
1 |
|
|
7 |
174-9630
|
Washer M9 conical spring with tooth |
1 |
|
|
8 |
174-4088
|
Spacer sleeve |
1 |
|
|
