Solution Tank Assembly

#PartDescription ReqNotesAvailability
1 174-8952 Solution tank lid 1
2 174-8953 Tank hinge 3
3 174-9630 Washer M9 conical spring with tooth 6
4 999-0784 Screw M8-1.25 x 16mm hex head stainless steel 6
5 999-1514 Screw M6-1 x 10mm button head socket stainless steel 5
6 174-8926 Hose support 1
7 274-6137 SOLUTION HOSE 1
8 174-3516 Hose clamp 1
9 174-8955 Hose barb elbow fitting 1
10 174-8956 O-ring 1
11 174-4162 Solution tank 1
12 174-8455 Drain hose assembly 1
13 174-8957 Hook 1
14 997-2000 Hose clamp 1
15 174-4163 Cross beam 1
16 174-8958 Edge protection (Sold by the foot) 28 in
17 174-8959 O-ring 1
18 999-9101 Screw M4-.7 x 10mm pan head stainless steel 2
19 174-8960 Drain hose cap 1
20 174-8961 Decal 1
21 374-2279 HOSE SUPPORT 1
22 999-0784 Screw M8-1.25 x 16mm hex head stainless steel 4
23 999-9097 Washer M8 flat stainless steel 4
