POWERBOSS SCV28 Solution Tank Assembly

#PartDescriptionPriceReqNotesAvailability
1 174-8748 Solution tank $730.09 1 usually ships 1-5 days
2 174-8749 Console $133.96 1 usually ships 1-5 days
3 174-8750 Seat assembly $256.81 1 usually ships 1-5 days
4 174-8751 Slide kit assembly $109.15 1 usually ships 1-5 days
5 174-8752 Seat switch $79.23 1 usually ships 1-5 days
6 174-8753 Long seat gasket $3.24 2 usually ships 1-5 days
7 174-8754 Short seat gasket $2.82 2 usually ships 1-5 days
8 174-8755 Vent plug $1.24 1 usually ships 1-5 days
9 174-8756 Seat bracket weldment $112.76 1 usually ships 1-5 days
10 174-8155 Solution tank plastic cover $61.40 1 usually ships 4-14 days
11 174-8757 Right hinge (OBSOLETE) $12.05 1 usually ships 1-5 days
12 174-8758 Left hinge $16.00 1 usually ships 1-5 days
13 174-8759 E-stop assembly $163.31 1 usually ships 1-5 days
14 999-0415 Screw 1/4-20 x 3/4 pan head slotted zinc plated $0.99 13 ships same day
15 174-2289 Screw 10 x 5/8 hi/lo $1.90 4 usually ships 4-14 days
16 174-6289 Bolt 1/4-20 x 7/8 hex head steel plated $0.97 2 usually ships 1-5 days
17 999-0493 Bolt 3/8-16 x 3/4 hex head stainless steel $0.99 4 ships same day
18 999-0069 Nut 5/16-18 hex $0.99 4 ships same day
19 999-0016 Washer 1/4 flat plain finish $0.99 12 ships same day
20 999-0024 Washer 5/16 flat stainless steel $1.34 4 ships same day
21 999-0120 Washer 3/8 SAE flat $0.99 4 ships same day
22 174-0536 Washer 1/4 $0.97 3 usually ships 4-14 days
23 999-0060 Washer 1/4 split lock plain finish $0.99 15 ships same day
24 999-0028 Washer 5/16 split lock plain finish $0.99 4 ships same day
25 999-0034 Washer 3/8 split lock plain finish $1.82 4 ships same day
26 174-0201 Cotter pin $1.20 1 usually ships 4-14 days
27 174-8760 Float switch $104.36 1 usually ships 1-5 days
28 174-1264 Clevis pin $3.04 1 usually ships 1-5 days
29 174-8761 Electrical panel assembly Call for price 1 usually ships 1-5 days
