| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
274-7498
|
Panel cover weldment kit |
$287.71
|
1 |
|
usually ships 1-5 days |
2 |
174-0198
|
Squeegee lift decal |
$4.07
|
1 |
|
usually ships 1-5 days |
3 |
174-5800
|
Squeegee lift cable |
$16.26
|
1 |
|
usually ships 9-11 days |
4 |
174-5802
|
Inner arm weldment |
$69.64
|
1 |
|
usually ships 1-5 days |
5 |
174-5803
|
Squeegee weldment lift arm |
$47.32
|
1 |
|
usually ships 1-5 days |
6 |
999-0492
|
Bolt 3/8 x 3/4 x 5/16 shoulder socket head |
$1.91
|
1 |
|
ships same day |
7 |
174-1264
|
Clevis pin |
$3.38
|
1 |
|
usually ships 1-5 days |
8 |
997-2506
|
Cotter pin |
$0.99
|
1 |
|
ships same day |
9 |
174-1181
|
Yoke |
$27.88
|
1 |
|
usually ships 9-11 days |
10 |
174-0190
|
Clevis pin |
$1.23
|
1 |
|
ships same day |
11 |
174-0201
|
Cotter pin |
$1.08
|
1 |
|
usually ships 9-11 days |
12 |
174-5160
|
Bolt 1/4-20 x .44 x 3/8 shoulder |
$1.08
|
1 |
|
ships same day |
13 |
174-5805
|
Handle weldment |
$50.19
|
1 |
|
usually ships 1-5 days |
14 |
174-0915
|
Rollpin .187 x 1 |
$1.08
|
1 |
|
usually ships 1-5 days |
