E30 ECO Disc Scrub Deck Assembly III

#PartDescriptionPriceReqNotesAvailability
1 174-3532 Threaded rod $13.07 2 usually ships 1-5 days
2 999-9097 Washer M8 flat stainless steel $0.99 2 ships same day
3 999-1120 Nut M10-1.5 nylon insert lock stainless steel $3.92 2 ships same day
4 174-3531 Weight $36.75 8 usually ships 1-5 days
7 174-9639 Clevis pin $6.99 2 usually ships 1-5 days
8 174-8991 Cotter pin $4.96 2 usually ships 1-5 days
9 374-0693 Washer M13 $3.74 4 usually ships 1-5 days
10 174-8992 Slide bearing $4.10 8 usually ships 1-5 days
11 274-7130 ROCKER $137.93 1 usually ships 1-5 days
12 274-0641 BACKING FILM $1.05 1 usually ships 1-5 days
13 997-2102 Cable tie $1.24 3 ships same day
14 174-6185 Cable tie large $1.24 2 usually ships 1-5 days
15 274-3442 RETAINER $126.09 1 usually ships 1-5 days
16 999-1372 Bolt M10-1.5 x 25mm hex head stainless steel $3.56 2 ships same day
17 174-8888 Washer $4.62 2 usually ships 4-14 days
18 999-0496 Nut M8-1.25 nylon insert lock stainless steel $1.08 2 usually ships 11-24 days
