| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
273-9332
|
3 phase wheel drive motor |
1 |
|
|
2 |
273-9333
|
Cable socket |
1 |
|
|
3 |
373-1355
|
Screw M4 x 8mm |
2 |
|
|
4 |
999-1619
|
Nut M4 hex stainless steel |
2 |
|
|
6 |
273-7023
|
Screw M6 x 12 |
2 |
|
|
8 |
273-9335
|
Wheel |
1 |
|
|
10 |
273-9336
|
Screw M8 x 30 |
6 |
|
|
11 |
273-9337
|
Threaded pin M8 x 10 |
2 |
|
|
18 |
273-9338
|
Lock washer |
6 |
|
|
